Yardistry YM12952 - Page 13

13 support@yardistrystructures.com
1pc.
- 1/8" D
r
ill B
it
(Y0040
0
-0
02)
1pc.
#2 x 2" Robertson Driver (Y00400-005)
1pc.
- Hex Driver (Y00400-004)
5pc.
Peak Loop
(Y20018-003)
5pc.
Carriage Bolt
(Y07428-260)
5pc.
Peak Post
(Y01000-094)
5pc.
1/4" Nut
(Y08490-200)
1pc.
- Post
Mount Set (4Pk)
(Y70819-216)
5pc.
Contour Washer
(Y05918-211)
3pc.
Peak Bracket
(Y00429-190)
5pc.
Spring Clip
(Y09490-001)
4pc.
Roof Peak Bracket
(Y00429-125)
1pc.
- 45º Twist Bracket LT
(2 PK)(Y70829-191)
1pc.
- 45º Twist Bracket RT
(2 PK)(Y70829-192)
1pc.
- Post
Mount Set (8Pk)
(Y70829-122)
2pc.
- Roof To Beam
Bracket Set (8Pk)
(Y70819-108)
(Y01030-347)
- Peak Cap Detail
2pc.
1pc.
- Peak Cap Centre
(Y01030-211)
1pc.
Tie Wrap Bracket (2Pk)
(Y70829-163)
1pc.
Tie Wrap Bracket (8Pk)
(Y70819-106)
1pc.
Double Tie Wrap
Bracket RT(2Pk)
(Y70829-213)
1pc.
- Centre Roof
To Beam Bracket Set
(2Pk) (Y70829-206)
1pc.
Steel Cable with Bracket
(Y70829-204)
1pc.
Double Tie Wrap
Bracket LT(2Pk)
(Y70829-214)
1pc.
- Beam to
Rafter Bracket (4Pk)
(Y70829-212)
4pc.
- Roof Edge
Centre
(Y01030-217)
Hardware Identification
( )
Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
(Y70830-103)
1pc.
- Corner Cap Set (4Pk)
1pc.
-
Roof Peak Set
(Y70829-202)
1pc.
- Roof To Beam
Bracket Set (10Pk)
(Y70819-218)
