Yardistry YM12952 - Step 21: Attach Roof Edges - Large Roof Assemblies; Ridge Edge Installation on Large Roofs

55 support@yardistrystructures.com
Y010XX-210
Roof Edge Middle x2 assemblies
#8 x 1 Hex Roofing Screw x13
Step 21: Attach Roof Edges - Large Roof Assemblies
Hardware
F21.1
26 x #8 x 1” Roong Screw
A: On the bottom of each Large Roof Assembly place one Ridge Edge Middle so the holes line up with the holes
in the Middle Panels then attach with 13 #8 x 1” Roong Screws per Large Roof Assembly. (F21.1 and F21.2)
Components:
2 x Ridge Edge Middle
#8 x 1” Roong
Screws
F21.2
Ridge Edge
Middle
(678) Mid
Fascia
(678) Mid
Fascia
Ridge Edge
Middle
Top
Bottom
Bottom
Middle Panel
Y010XX-210
Roof Edge Middle x2 assemblies
#8 x 1 Hex Roofing Screw x13
