65 support@yardistrystructures.com
A: At each corner place one Corner Cap tight to Fascia Assemblies and End Fascias, push up so the bottom is
tight to the bottom of the fascia then attach with four #8 x 3/4” Sheet Metal Screws per Corner Cap. (F28.1 and
F28.2)
Hardware
16 x #8 x 3/4” Sheet Metal Screw
Components:
4 x Corner Cap
Corner
Cap
Fascia
Assembly
F28.1
F28.2
#8 x 3/4” Sheet
Metal Screw
End Fascia
Tight
x 3
Step 28: Attach Corner Caps
#8 x 3/4”
Sheet Metal
Screw
To Next Page
