Yardistry YM12952 User Manual

8 support@yardistrystructures.com
Part Identification ( )
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
8pc. (460) Plinth Long FSC
276.2mm (10-7/8")
Y50229-460
200mm (7-7/8")
16pc. (459) Plinth FSC
Y50229-459
Y50229-694
4pc. (694) Outer Ends FSC 2532.9mm (99-3/4")
4pc. (692) Beam Long Ends FSC 1722.4mm (67-13/16")
4pc. (1006) 6 x 9 Post FSC 2336.8mm (92")
Y70229-696
2pc. (696) 6 x 6 Post FSC 2336.8mm (92")
Y70229-1006
2pc. (691) Beam Long Inside FSC 2590.8mm (102")
Y50229-692
Y50229-691
2pc. (1003) Beam Short Right FSC 1763.3mm (69-7/16")
Y50229-1003
Y70229-705
6pc. (705) Gusset RT FSC 1015mm (39-15/16")
2pc. (1005) Beam Short Centre FSC 2422.1mm (95-3/8")
Y50229-1005
2pc. (1002) Beam Short Left FSC 1763.3mm ( 69-7/16")
Y50229-1002
2pc. (693) Outer Beam Centre FSC 1039.7mm (40-15/16")
Y50229-693
Y50229-1004
4pc. (1004) Beam Short End FSC 555.4mm (21-7/8")
Y70229-706
6pc. (706) Gusset LT FSC 1015mm (39-15/16")
