24
Power Sweeper
»
Operator’s Manual
Parts List
|
No. Description
Qty
109 Arm Pulley 1
110 Clutch Lever Seat 1
111 Screw M5X16 12
112
Key A8X16
1
113 Bevel Gear - Small 1
114 Bevel Gear Shell 2
115 Bearing 6005 2
116 Bevel Gear - Big 1
117 Output Shaft 1
118 Bevel Gear Shell Gasket 4
119 Nut M5 12
120 Clutch Revolving Arm II 1
121 Clutch Revolving Arm I 1
122 Spring 1
123 Screw ST4.2X16 29
124 Shell 1
125 Straight Pin 8X70 1
126 Wheel Axle 1
127 Washer 3
128 Driving Gear Wheel 1
129 Bearing 61804 2
130 Oil Seal A19X27X6 2
131 Oil Seal Retainer 2
132 Worm Bearing Seat I 1
133 Washer 3
134 Driving Gear Pulley 2
135 Worm Shaft Sleeve 2
136 Straight Pin 4X18 2
137 Jaw Clutch I 2
138 Shell II 1
No. Description
Qty
1* Moving Handle 2
2* Washer 6 4
3*
Cross Recessed Pan Head
Screw M6x20
4
4*
Hexagon Flange Bolt M8x20
2
5* Clip 4.0 2
6* Pin 2
7* Hexagon Flange Bolt M8x45 2
8* Mounting Plate 1
9* Hexagon Flange Bolt M8 4
10* Side Plate- Right 1
11* Back Plate 1
12* Hexagon Flange Bolt M5 44
13* Rubber Sheet 1
14* Nut M4 4
15* Spring Washer 4 4
16* Washer 4 4
17* Lower Plate 1
18* Hex Nut M6 4
19* Adjustable Height Support Wheel 2
20*
Cross Recessed Pan Head
Screw M4x10
4
21*
Side Plate-Left
1
22* Hexagon Flange Bolt M5x12 44
23* Upper Plate 1
No. Description
Qty
139 Jaw Clutch II 2
140 Worm Bearing Seat 1
141 Gearbox Belt Pulley 1
142 Fork I 1
143 Fork Crown Cover 2
144 Clutch Band Spring 2
145 Worm Bearing Seat II 1
146 Fork II 1
147 O-Ring 11.8X1 1
148 O-Ring 14X1 1
149 Driving Shaft Sleeve 1
150 Bearing 6001 1
151 Cotter Pin 4X25 2
152 Circlip 12 2
153 Worm Wheel 2
154 Bearing 608-2Z 1
155 Oil Seal A12X19X5 1
156 Round Pin 5X30 1
157 Worm Gear 1
158 Pin 2
159 Gearbox Side Guard A 1
160 Tension Pulley Assembly 2
161 Clutch lever Seat (with hole) 2
162 Gearbox Side Guard B 1
163 Extension Shaft 2
164 Extension Cover Plate - Right 1
165 Extension Cover Plate - Left 1
166 Nut M6 8
167 Bolt M6x16 8
OPTIONAL
DUST COLLECTION BUCKET
32530US25M100.indd 24 2016/9/23 14:48:55
