YARDMAX YP7065 - Parts List

23
|
Parts List
PARTS LIST
No. Description Qty
1 Bolt M10X70 2
2 Washer 10 4
3 Brush Guard 2
4
Brush II 14
5 Brush Sleeve 10
6 Brush I 2
7 Brush Shaft Weldment 2
8 Nut M6 10
9 Blot M6X12 9
10 Blot M8X65 4
11 Washer 8 24
12 Gear Holder - Left 1
13 Gear Box 1
14 Washer 8 12
15 Gear Holder- Right 1
16 Nut M8 28
17 Blot M8X45 7
18 Nut M8 3
19 Adjustable Height Support Wheel 2
20 Nut M10 3
21
Washer-upper 1
22 Guiding Fork 2
23 Blot M10X50 2
24 Spring Washer 8 12
25 Blot M8X20 13
26 Guard Plate 1
27 Guard Sleeve 2
28 Syphon 1
29 Blot M8X40 6
30 U Shape Plate 1
31 Nut M8 7
32 Circlips 2
33 Plastic Washer 20
34 Plastic Bushing 6
35 Washer 10 2
36 Round Pin 6X40 2
No. Description Qty
37 Front Stand Weldment 1
38 Gimbal joints 1
39 Bearing 6003 4
40 Shaft 1
41 Key A 5X20 1
42 Bearing House 1
43 Circlip 4
44 Bushing 1
45 Pulley 1
46 Washer 1
47 Swing Spring 2
48 Blot M10X20 2
49 Nut M6 3
50 Blot M6X25 2
51 Blot M6X16 2
52 Blot M8X16 4
53 Steering Fixing Plate Weldment 1
54 Washer 6 10
55 Cover Board 1
56 Tensioner Stand 1
57 Bolt M10X40 1
58 Clutch Cable 1
59 Bushing 1
60 Screw 1
61 Spring 1
62 blot M8X30 1
63 Tensioner Fixing Plate II 1
64 Washer 1
65 Driving Assy Guard 1
66 Blot M6X12 4
67 Engine Base 1
68 Tyre - Left 1
69 Pusher Support 1
70 Line Card 25 5
71 Round Stem 2
72 Holder 4
No. Description Qty
73 Ferrule 2
74 Wing Nut 2
75 Blot M8X85 2
76 Handle 1
77 Cable throttle 1
78 Blot M6X60 1
79 Throttle Control Assy 1
80 CKA Clutch Cable I 1
81 CKA Clutch Cable 1
82 Screw M6X60 1
83 Clutch Handle Cover 3
84 Clutch handle 3
85 Screw M6X40 2
86 Engine 1
87 Spring Washer 6 8
88 Bolt M6X14 4
89 Screw M8X20 2
90 Driving Assembly 1
91 Washer 2
92 Round Pin 8X45 2
93 Tyre - Right 1
94 DK Circlip 2
95 Handle Grip 1
96 Turning Handle 1
97
Handle Fixing Plate 2
98 Belt 8PJ685 1
99 Belt 8PJ620 1
100 Bolt 5/16" 2
101 Washer 8 3
102 Engine Pulley 2
103 Key B5*4.76*45 1
104
Washer 1
105 Bolt 5/16-24UNF*30 1
106 Spring 1
107 Bolt M8X70 4
108 Nut 5/16-24UNF 1
