16
Operation
CAUTION!
• Before using the log splitter, make sure that the work area is clear of obstructions, clutter,
children, and pets. Work only in an area with ample lighting.
• Dress properly. Wear rubber gloves and non-skid, steel-toed footwear.
• When splitting logs, wear safety goggles to protect against eye injury.
1. CHECK THE OIL
• Ensure the log splitter is disconnected from the power supply.
• Using the support leg handle, stand the log splitter on the end with the wheels.
• Loosen the oil drain bolt and remove from the oil tank to see the attached oil dipstick.
• Wipe the dipstick clean and then re-insert
it back into the oil tank. Pull up the dipstick
and check if the oil level is between the
2 grooves on the dipstick.
• If there is not enough oil in the tank, refer
to “Replacing the Hydraulic Oil” in the
Maintenance section.
• After verifying that the oil level is correct,
insert the bolt with dipstick back into the
oil tank. Tighten the drain bolt in order to
avoid leakage, and then place the
log splitter back to its normal
horizontal position.
Oil level
Oil drain bolt
with dipstick
NOTE: Check for oil leaks around the ram cylinder and other
points. Refer to the Troubleshooting section if there are oil leaks.
