FIG. C PARTS LIST ENGINE DETAIL
Item Part Number Description Qty.
1 11310-Z1S0110-0B00 Crankcase Subassembly 1
2 11011-Z1S0210-0000 Oil Drain Tube, 165 × 16, Blue White Zinc 1
3 90408-Z010110-0000 Washer, Ø10 × Ø15.8 × 1.5 1
4 11007-Z010110-0000 Drain Plug Bolt, M10 × 1.25 × 15, Blue White Zinc 1
5 90682-Z1S0110-0001 Oil Seal, Ø25 × Ø41.25 × 6 2
6 90547-0205-00 Bearing, 6205 P53 2
7 16400-Z810210-0000 Governor Gear Assembly 1
8 37060-Z010120-0000 Engine Oil Sensor, W/O Nut 1
9 90001-0614-01 Hexagon Flange Bolt, M6 × 14, Blue White Zinc 3
10 90305-Z010210-01 Hexagon Flange Nut, M10, Blue White Zinc 1
11 16061-Z010110-0000 Governor Arm 1
12 90408-Z010210-0000 Washer, Ø6.2 × Ø15 × 0.6 1
13 90501-Z010110-0000 Pin, Blue White Zinc 1
14 11001-Z330120-0000 Crankcase Gasket 1
15 90502-0812-00 Pin, 8 × 12 2
16 15010-Z1S0110-0B01 Oil Dipstick Subassembly 1
17 11411-Z1S0110-0B00 Crankcase Cover 1
18 15030-Z010130-OB01 Engine Oil Plug Subassembly 1
19 90001-0832-01 Hexagon Flange Bolt, M8 × 32, Blue White Zinc 6
20 90001-0612-01 Hexagon Flange Bolt, M6 × 12, Blue White Zinc 11
21 12410-Z300120-0000 Cylinder Head Cover Subassembly, Blue White Zinc 1
22 12004-Z010110-0001 Cylinder Head Cover Gasket 1
23 17004-Z1S0110-0001 Breather Tube 1
24 14312-Z010110-0000 Valve Lock Nut 2
25 14314-Z010110-0000 Valve Adjusting Nut 2
26 14311-Z010110-0000 Valve Rocker 2
27 14313-Z010110-0000 Valve Adjusting Bolt 2
28 14090-Z010110-0000 Lifter Stopper Plate Subassembly, Blue White Zinc 1
29 12003-Z010110-0000 Cylinder Head Bolt, M8 × 60, Blue White Zinc 4
30 12109-Z810110-0000 Valve Lock Clamp 4
31 12112-Z810210-0000 Valve Spring Retainer 2
32 12103-Z010110-0000 Valve Spring 2
33 12101-Z810210-0000 Seal Guide 1
34 12140-Z1S0110-0B00 Cylinder Head Subassembly 1
