model no. 060-1314-4 | contact us: 1.866.523.5218
40
FIG. C PARTS LIST ENGINE DETAIL
Item Part Number Description Qty.
35 30010-Z010110-0000 Spark Plug, F6RTC 1
36 12131-Z530320-0000 Cylinder Head Gasket 1
37 90502-1114-00 Pin, 11 × 14 2
38 12121-Z810120-0000 Exhaust Valve 1
39 12111-Z810110-0000 Inlet Valve 1
40 14071-Z440110-0000 Valve Rod 2
41 14081-Z040110-0000 Valve Lifter 2
42 90207-Z330120-0000 Stud, M6 × 105, Blue White Zinc 2
43 90203-Z010110-0000 Stud, M8 × 34, Black Zinc 2
44 CMP-QGT-002 Cylinder Head Assembly Kit 1
45 13300-Z1S0110-0000 Crankshaft Assembly 1
46 14200-Z1S0110-0009 Camshaft Assembly 1
47 13200-Z140210-0099 Piston Rings Set 1
48 13111-Z810120-0000 Piston 1
49 13121-Z810110-0000 Piston Pin, Ø13 × Ø45.9 1
50 13122-Z510210-0000 Piston Pin Clip 2
51 13010-Z810210-0000 Connecting Rod 1
52 30360-Z330110-H301 Support Control Box Subassembly 1
53 90001-0512-01 Hexagon Flange Bolt, M5 × 12, Blue White Zinc 1
54 30300-Z1S0110-0001 Starting Motor Assembly 1
55 90103-0455-53 Screw, M4 × 55, Black Zinc 2
56 90502-0810-00 Pin, 8 × 10 2
57 90001-0630-01 Hexagon Flange Bolt, M6 × 30, Blue White Zinc 3
58 90684-Z030120-0000 Clip 1
59 37050-Z010210-0000 Oil Protector, Zinc Plated 1
60 30140-Z051810-0000 Charging Coil 1
61 90001-0625-01 Hexagon Flange Bolt, M6 × 25, Blue White Zinc 4
62 30400-Z330110-0001 Ignition Coil 1
63 30423-Z1S0110-0000 Ignition Coil Stop Engine Wire 1
64 13510-Z050210-0000 Flywheel Subassembly 1
65 19352-Z010110-0000 Impeller 1
66 28002-Z0L0110-0000 Starter Pulley, Blue White Zinc 1
67 13501-Z010110-0000 Flywheel Nut, M14 × 1.5, Blue White Zinc 1
68 28110-Z1S0210-VG00 Shroud 1
To Next Page
