Yardworks 100666 - ENGINE DETAIL PARTS LIST (FIG. C)

model no. 060-1314-4 | contact us: 1.866.523.5218 model no. 060-1314-4 | contact us: 1.866.523.5218
41
FIG. C  PARTS LIST  ENGINE DETAIL
Item Part Number Description Qty.
69 19304-Z1S0110-0000 Cylinder Body Shroud, Blue White Zinc 1
70 19340-Z050120-0000 Lower Shield, Blue White Zinc 1
71 90204-Z520110-0000 Stud, M6 × 92.8 1
72 90007-0612-A1 Hexagon Flange Bolt, M6 × 12, Blue White Zinc 4
73 28200-Z1S0210-H600 Recoil Starter Assembly 1
74 90001-0608-01 Hexagon Flange Bolt, M6 × 8, Blue White Zinc 3
75 90408-0600-E1 Washer, Blue White Zinc 3
76 80057-Z1S0110-0001 Front Snow Guard 1
77 90314-0600-31 Nut, M6, Blue White Zinc 1
78 16002-Z050110-0000 Carburetor Insulator Gasket 1
79 16003-Z010110-0001 Carburetor Insulator Plate 1
80 16001-Z010110-0000 Carburetor Gasket 1
81 16100-Z1S0210-R909 Carburetor Assembly 1
82 90740-Z010210-0000 Clamp, Ø7.5, Blue White Zinc 2
83 90686-Z010710-0001 Fuel Pipe, Ø4.5 × Ø8.5 × 160 1
84 30431-Z010110-0000 Rubber Jacket, Ø9.5 × Ø11 × 90, Black 1
85 17001-Z010210-0000 Air Cleaner Gasket 1
86
16161-Z151310-0000 Main Jet, Standard 1
16161-Z151110-0000 Main Jet, Altitude 3000-6000 feet 1
16161-Z150910-0000 Main Jet, Altitude 6000-8000 feet 1
87 16112-Z010110-0000 Seal Ring, Float 1
88 90681-Z010710-0000 Seal Ring 1
89 CMP-HYQ-002 Carburetor Assembly Kit 1
90 16520-Z1S0110-R900 Throttle Control Assembly, Blue White Zinc 1
91 16012-Z010110-0000 Throttle Valve Returning Spring 1
92 90684-Z030210-0000 Clip 1
93 16070-Z010110-0000 Governor Support Subassembly, Blue White Zinc 1
94 16072-Z010110-0000 Governor Support Bolt, M6 × 21, Blue White Zinc 1
95 90305-0600-31 Hexagon Flange Nut, M6, Blue White Zinc 3
96 16063-Z1S0110-0000 Spring, Governor, Ø6 × Ø0.8 × 127, Blue White Zinc 1
97 16062-Z010110-0000 Governor Rod, Blue White Zinc 1
98 17100-Z1S0110-0001 Air Cleaner 1
99 90314-Z130210-0000 Nut, M6 × 17, Chrome Plated 2
100 16210-Z330110-0001 Primer Bulb 1
