model no. 060-1314-4 | contact us: 1.866.523.5218
42
FIG. C  PARTS LIST  ENGINE DETAIL
Item Part Number Description Qty.
101 35540-Z330110-0002 Stop Engine Switch Subassembly 1
102 18001-Z010110-0000 Exhaust Outlet Gasket 1
103 18100-Z1S0110-0000 Muffler Assembly 1
104 90303-0800-31 Hexagon Flange Nut, M8, Blue White Zinc 2
105 18140-Z1S0310-HL02 Scald Resistant Cover 1
106 90001-0616-01 Hexagon Flange Nut, M6 × 16, Blue White Zinc 3
107 CMP-XSQ-002 Muffler Assembly Kit 1
108 16620-Z1S0110-HL03 Fuel Tank 1
109 16730-Z1S0110-Q201 Fuel Tank Cover 1
110 16667-Z330110-0001 Fuel Tank Decorated Plate 1
111 16680-Z010110-0001 Fuel Tank Oil Outlet Subassembly 1
