FIG. E PARTS LIST AUGER
Item Part Number Description Qty.
1 30913070185000 Hexagon Flange Bolt, M8 × 20, Blue White Zinc 6
2 23091000060001A Spherical Bearing Sheath, Black 2
3 30693010055000 Outer Spherical Ball Bearing, 47 × 20 × 31 3
4 2309400003A Spherical Bearing Support, SMF5040 2
5 23093000195000B B Pin, White Zinc 4
6 23053000245000A Auger Connecting Shaft, 100 × 25.4, Black 2
7 23053000055000A Shear Pin, 8 × 42.5, Blue White Zinc 4
8 23055000190243A Right Auger Assembly, 24" 1
9 23052000215000A Auger Shaft Washer, 25.6 × 40 × 2 2
10 23029000165000A Worm Gear Box Assembly, 24" 1
11 23055000180243A Left Auger Assembly, 24" 1
12 30313030015000 Hexagon Locking Nut, M6, Black Zinc 2
13 23055000170243A Fan Impeller Assembly, 35# 1
14 30223010055000 Hexagon Socket Head Cap Screw, M6 × 40, Black Zinc 2
15 30913090015000 Half-round Head Square Neck Bolt, M8 × 16, Blue White Zinc 4
16 30323060035000 Flange Locking Nut, M8, Hexagon, Blue White Zinc 9
17 2303200141A Snow Shovel Plate, 24" 1
18 23041000150243A Skid Shoes 2
19 30913090045000 Half-round Head Square Neck Bolt, M8 × 25, Blue White Zinc 4
20 23035000040027B Auger Housing Assembly, 24" 1
21 30323060015000 Flange Locking Nut, M6, All Metal Hexagon, Blue White Zinc 2
22 23092000075000A Chute Tool Bracket,1.2, 39.2 × 30.4 × 13, White Zinc 2
23 30913090035000 Half-round Head Square Neck Bolt, M6 × 16, Blue White Zinc 2
24 2304100024A Chute Tool 1
25 2303300002A Bushing, Ø8 × Ø12 × 7, White Zinc 1
26 2303800001A Tension Spring, Big Tension Pulley, White Zinc 1
27 23052000125000B Pressing Plate, Bearing, 2, Ø95 × 8.5, White Zinc 1
28 23032000675000A Bushing, 10.5 × 35 × 1, Large Tension Board, White Zinc 1
29 23032000635000A Large Tension Board, 313.3 × 40, White Zinc 1
30 23034000535000A Bushing, 35 × 6.1, Large Tension Board 1
31 30313090085000 Hexagon Locking Nut, M10, Blue White Zinc 1
32 23035000055000A Big Auger Pulley, 14 × 189.2 × 21.5, Black 1
33 31013010015000 Flat Key, C6 × 20, Black 1
