Yardworks 100666 - AUGER PARTS LIST (FIG. E)

model no. 060-1314-4 | contact us: 1.866.523.5218
50
FIG. E  PARTS LIST  AUGER
Item Part Number Description Qty.
34 23032000335000A Thickened Big Washer, Ø8.2 × Ø30 × 3.7, White Zinc 1
35 30913040115000 Hexagon Bolt, M8 × 25, Blue White Zinc 1
36 30933010015000 Small Carriage Bolt, M8 × 40, Blue White Zinc 1
37 23034000555000A Sheath, Large Tension Wheel, 20 × 18.3 1
38 23032000105000C Large Tension Pulley, Ø66.5 × 36.2,1.5 1
39 23034000545000A Sheath (Thin), Large Tension Wheel, 20 × 6.5 1
40 23071000230001A Discharge Chute Antifriction Mat, Black 1
41 30733010025000 Self-plugging Rivet, 4 × 15 4
42 A26800700201 Big Washer, Ø8 × Ø24 × 2.0, Blue White Zinc 4
43 A26800500801 Hexagon Locking Nut, M8, White Zinc 4
