Yardworks 100666 - HANDLE PARTS LIST (FIG. G)

model no. 060-1314-4 | contact us: 1.866.523.5218 model no. 060-1314-4 | contact us: 1.866.523.5218
55
FIG. G  PARTS LIST  HANDLE
Item Part Number Description Qty.
1 30113010265000 Self-tapping Screw, ST4.2 × 8, Black Zinc 11
2 23041000090243A Right Decorative Ring, ABS750SW 1
3 23041000060027A Light Panel 1
4 2308900011A LED Light Assembly, Right 1
5 30113010255000 Self-tapping Screw, ST4.2 × 16, Black Zinc 6
6 2304100022A Badge, Chrome 1
7 2308900010A LED Light Assembly, Left 1
8 23041000080243A Left Decorative Ring 1
9 2308100003A Panel Wiring Harness 1
10 2281100002B Cable Pressing Plate 2
11 30113010095000 Self-tapping Screw, ST4.2 × 12, Black Zinc 10
12 30313090025000 Hexagon Locking Nut, M8, White Zinc 7
13 23065000260265A Panel Fixed Plate Assembly, 463 × 166 × 210 1
14 30913090095000 Half-round Head Square Neck Bolt, M8 × 40, Blue White Zinc 4
15 23062000830265A Front Adjustment Plate,165 × 35 1
16 A26800104801 Self-tapping Screw, ST5 × 30, Blue White Zinc 2
17 30512050035000 Big Washer, 5, Blue White Zinc 2
18 30113010125000 Self-tapping Screw, ST4.8 × 12, Black Zinc 4
19 23041000070027A Top Panel 1
20 20114000605000A Rocker Switch, 125V, 20A 1
21 A26809003801 Open Pin, 1.5 x 31.5 4
22 30512050025000 Big Washer, 8, Blue White Zinc 3
23 23068000135000B Gear Pressing Spring, 14.5 × 33.75, White Zinc 3
24 23063000525000A Left Adjustment Lever, T=3, 248.9 × 42.5 1
25 23066000135000A Handle, 41 × 41 × 63, Black 3
26 20313000995000A Hexagon Flange Bolt, M8 × 50, Blue White Zinc 3
27 23032001045000A Front Adjustment Lever, T=3, 250.7 × 14.5 1
28 2306200087A Right Adjustment Lever, 65Mn 1
29 23062000800265A Right Upper Handle, 25 × 2.5 1
30 23062000790265A Left Upper Handle, 25 × 2.5 1
31 30313090055000 Hexagon Locking Nut, M5, Blue White Zinc 2
32 23062000820265A Right Trigger, T=2, 220 × 89.5 × 42.5, Black 1
33 23063000075000A Trigger Bolt, M5 × 45, White Zinc 2
