Yardworks 100666 - HANDLE PARTS LIST (FIG. G)

model no. 060-1314-4 | contact us: 1.866.523.5218
56
FIG. G  PARTS LIST  HANDLE
Item Part Number Description Qty.
34 23066000145000A Trigger Isolation Gasket, 16 × 13.2 × 19.2, Black 2
35 30913070135000 Hexagon Flange Bolt, M6 × 55, Blue White Zinc 2
36 30423010095000 Shaft Elastic Circlip, 6, Black 1
37 23068000295000A Self-locking Tension Spring, 1 × 28, White Zinc 1
38 23061000480301A Handle Support Unit 2
39 30313090035000 Hexagon Locking Nut, M6, Blue White Zinc 2
40 23065000275000A Self-locking Plate Assembly, Right Trigger, 62.5 × 36 × 30, Black 1
41 23063000515000A Self-locking Fixed Pin Shaft, 6 × 33, Black 1
42 23068000325000A Self-locking Cable, 745 mm 1
43 A26800315201
Cross Recessed Countersunk Head Screw, ST4.2 × 10, Black
Zinc
4
44 23069000105000A Handle, Heated, Ø34.5*132 2
45 23062000810265A Left Trigger, T=2, 220 × 89.5 × 42.5, Black 1
46 23053000055000A Shear Pin, 8 × 42.5, Blue White Zinc 4
47 23093000195000B B Pin, White Zinc 4
