YASKAWA AC Drive CH700
Catalog
｜ KAEP C710617 24 ｜
YASKAWA
Number/
Code
Ca
pacity
/
the
Model
Catalog
Selecting
Basi
c
Inst
ructi
ons
mode.
⑦
Basic Instructions
Outstanding operability and quick setup
Keypad Names and Functions
① RUN LED
Lit while the drive is operating
the motor.
② ALM LED
The drive lights up if a fault is
detected.
Flashes when minor faults,
tuning errors and operational
errors occur.
⑤ LO/RE LED
Lit：When the keypad
is selected for Run
command and frequency
reference control
(
LOCAL
)
.
Off：When a device other than
the keypad is selected
③
for Run command and
frequency reference
control
(
REMOTE
)
.
⑥ RUN Key
Starts the drive in LOCAL
⑥
⑦ STOP Key
Stops drive operation.
⑧ Com port
⑧
For connecting to a PC
⑨
(
DriveWizard
)
, a USB copy
unit or a LCD keypad.
⑨ LED Status Ring
The corresponding lamp
lights depending on the
operation status.
⑩ QR code
Import the dedicated
smartphone application
“DriveWizard Mobile” and
use it to retrieve product
information.
③ Function Keys
:
F1, F2, F3
The functions of the function
key depend on the menu that
is being displayed. The name
of each function appears in the
lower half of the display window.
④ Display Operation Keys
:
LEFT Arrow Key
• Moves the cursor to the left.
• Returns to the previous screen.
UP Arrow Key /
DOWN Arrow Key
• Scrolls up to display the
next item.
• Scrolls down to display the
previous item.
• Selects parameter numbers.
• Increments setting values.
• Decrements setting values.
RIGHT Arrow
(
RESET
)
Key
• Moves the cursor to the right.
• Proceeds to the next screen.
• Resets the drive to clear a fault.
• Used as the start key in
Auto
-
Tuning Mode.
ENTER Key
• Inputs parameter numbers
and setting values. Press to
enter values, edit parameters
and set the control mode.
• Switches between displays
with selection of menu items.
Note
:
QR code is a trademark of
DENSO WAVE INCORPORATED.
Keypad LED
Indicator LED
Lit
Flashing
Flashing Quickly
OFF
Motor running.
The motor is performing
ramp to stop.
The Run command was
inputted when the frequency
reference was 0 Hz
With a Run command inputted from an external command
when the Run command source was in LOCAL, the Run
command source switched to REMOTE.
When the drive was not in the Drive Ready
(
READY
)
state,
a Run command was inputted from an external command.
An emergency stop command has been inputted.
The Safe Disable input function was running and the drive
output was shut off.
When the Run command source was REMOTE, the STOP
key on the keypad was pressed and the motor was stopped.
The power supply for the drive is turned on when the Run
command is inputted from an external source.
Drive is stopped.
A fault was detected.
Minor fault was detected.
Operation error was detected.
Auto
-
Tuning was detected.

Normal operation
Sets the Run command
source to the keypad
(
LOCAL
)
.


Sets the Run command
source to a non
-
keypad
external command
(
REMOTE
)
.
How the RUN LED works
:
Drive output frequency
/
Frequency reference
RUN LED
during stop
0 Hz
6 Hz
RUN
STOP
RUN
STOP
OFF
Flashing
OFF
Flashing
Lit
OFF
