YASKAWA CR700

16 UL Standards
106 YASKAWA TOEPC71061723A YASKAWA AC Drive CR700 Quick Start Guide
Model Terminal
Recomm. Gauge
AWG, kcmil
Applicable Gauge
(IP20 Applicable
Gauge
*1
)
AWG, kcmil
Wire Stripping
Length
*2
mm
Terminal Screw
Tightening
Torque
N∙m (lbf∙in)
Terminal
Screw Size
Shape
2033
R/L1, S/L2, T/L3 6
14 - 6
(14 - 6)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 6
14 - 6
(14 - 6)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
-, +1, +2 3
14 - 3
(14 - 3)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 10
14 - 10
(14 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
8
10 - 8
(-)
- M5
Phillips/slotted
combo
2.0 - 2.5
(17.7 - 22.1)
2047
R/L1, S/L2, T/L3 3
14 - 3
(8 - 3)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 4
14 - 4
(10 - 4)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1, +2 1
14 - 1
(8 - 1)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
B1, B2 8
14 - 8
(14 - 8)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
6
8 - 6
(-)
- M6
Phillips/slotted
combo
5.4 - 6.0
(47.8 - 53.1)
2060
R/L1, S/L2, T/L3 1
14 - 1
(6 - 1)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
U/T1, V/T2, W/T3 3
14 - 3
(6 - 3)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
-, +1, +2 1/0
14 - 1/0
(4 - 1/0)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
B1, B2 8
14 - 8
(14 - 8)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
6
6 - 4
(-)
- M6
Phillips/slotted
combo
5.4 - 6.0
(47.8 - 53.1)
2075
R/L1, S/L2, T/L3 1/0
14 - 1/0
(6 - 1/0)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
U/T1, V/T2, W/T3 2
14 - 2
(6 - 2)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
-, +1, +2 2/0
14 - 2/0
(4 - 2/0)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
B1, B2 6
14 - 6
(14 - 6)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
6
6 - 4
(-)
- M6
Phillips/slotted
combo
5.4 - 6.0
(47.8 - 53.1)
2088
R/L1, S/L2, T/L3 1/0
6 - 1/0
(6 - 1/0)
27 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
U/T1, V/T2, W/T3 1/0
6 - 1/0
(6 - 1/0)
27 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
-, +1 2/0
2 - 2/0
(2 - 2/0)
27 M8
Hex socket cap
(WAF: 6 mm)
10 - 12
(89 - 107)
B1, B2 4
14 - 4
(10 - 4)
21 M6 Slotted (-)
3 - 3.5
(27 - 31)
6
6 - 4
(-)
- M6 Hex bolt (+)
5.4 - 6.0
(47.8 - 53.1)
