6.2 Motion Command Details
6.2.6 Jog Mode (FEED)
6-47
Motion Commands
( 5 )
Tim
ing Charts
[ a ]
Normal Execution
[ b ]
Execution when Aborted
[ c ]
Execution whe
n an Alarm Occurs
OW
08 = 7 (FEED)
IW
08 = 7 (FEED)
IW
09, bit 0 (BUSY)
IW
09, bit 8 (COMPLETE)
IW
09, bit 3 (F
AIL)
IW
0C, bit 0 (DEN)
1 scan
1 scan
OW
09, bit 1 (ABORT)
OW
08 = 7 (FEED)
IW
08 = 7 (FEED)
IW
09, bit 0 (BUSY)
IW
09, bit 8 (COMPLETE)
IW
09, bit 3 (F
AIL)
IW
0C, bit 0 (DEN)
Alarm
1 scan
OW
08 = 7 (FEED)
IW
08 = 7 (FEED)
IW
09, bit 0 (BUSY)
IW
09, bit 8 (COMPLETE)
IW
09, bit 3 (F
AIL)
IW
0C, bit 0 (DEN)
211
213
