6.2 Motion Command Details
6.2.25 Change Position Loop Integral Time Const
ant (KIS)
6-94
( 4 )
Timing Charts
[ a ]
Normal End
[ b ]
Error En
d
IW
09
Bit 8
Command Execution
Completed
T
urns ON when KIS command execution has been completed.
(cont’d)
Parameter
Name
Monitor Contents
OW
08 = 26 (KIS)
IW
08 = 26 (KIS)
IW
09, bit 0 (BUSY)
IW
09, bit 8 (COMPLETE)
IW
09, bit 3 (F
AIL)
Undefined length
of time
OW
08 = 26 (KIS)
IW
08 = 26 (KIS)
IW
09, bit 0 (BUSY)
IW
09, bit 8 (COMPLETE)
IW
09, bit 3 (F
AIL)
Undefined length
of time
258
260
