10.4 Motion Parameter Details
10.4.5 Inverter Input Data Details
10-46
10.4.5 Inverter Input Data Details
Register
No.
Name Varispeed G7 Varispeed F7 VSminiV7
IW10 Status
Bit 0
Alarm
ALM
Alarm
ALM
Alarm
ALM
Bit 1
Warning
WARNG
Warning
WAR NG
Warning
WAR NG
Bit 2
Command Ready
CMDRDY
Command Ready
CMDRDY
Command Ready
CMDRDY
Bit 3
Base Block
BB OFS
Base Block
BB OFS
Base Block
BB OFS
Bit 4
Power ON
PON
Power ON
PON
Power ON
PON
Bit 5
During Running
RUNX
During Running
RUNX
During Running
RUNX
Bit 6
Zero Speed
OSP
Zero Speed
OSP
Zero Speed
OSP
Bit 7
Reverse Operation
REV
Reverse Operation
REV
Reverse Operation
REV
Bit 8
During Reset
RESET
During Reset
RESET
During Reset
RESET
Bit 9
During Speed Coincident
AGREE
During Speed Coincident
AGREE
During Speed Coincident
AGREE
Bit A
Inverter Ready
INV_READY
Inverter Ready
INV_READY
Inverter Ready
INV_READY
Bit B
OPE Error
OPE
OPE Error
OPE
OPE Error
OPE
Bit C
Momentary/Power Cut
UV_R
Momentary/Power Cut
UV_R
Momentary/Power Cut
UV_R
Bit D
Remote Operation
REMOTE
Remote Operation
REMOTE
Remote Operation
REMOTE
Bit E
Reserved by the system. Reserved by the system. Reserved
by the system.
Bit F
IW11 Output Frequency
Unit depends on the
inverter user constant
o1-03.
Unit depends on the
inverter user constant
o1-03.
Unit depends on the
inverter user constant
n035.
IW12 Output Current
Unit: 0.1 A or 0.01 A Unit: 0.1 A or 0.01 A Unit: 0.1 A or 0.01 A
IW13 Motor Speed (Option)
Unit depends on the
inverter user constant
o1-03.
(Invalid in V/f with PG
control mode)
Unit depends on the
inverter user constant
o1-03.
(Invalid in V/f with PG
control mode)
Unit depends on the
inverter user constant
n035.
(Output Frequency in V/f
with PG control mode)
IW14
Torque Reference (U1-09)
(Option)
Unit: 0.1%
(Invalid in V/f with PG
and V/f control mode)
Unit: 0.1%
(Invalid in V/f with PG
and V/f control mode)
Unit: 0.1%
(Invalid in V/f with PG
control mode)
IW15 Encoder Count (Option)
Unit: pulse
(Invalid when an optional
PG is not connected.)
Unit: pulse
(Invalid when an optional
PG is not connected.)
Reserved by the system.
IW16
Frequency Reference
(U1-01) (Option)
Unit depends on the
inverter user constant
o1-03.
Unit depends on the
inverter user constant
o1-03.
Unit depends on the
inverter user constant
n035.
IW17
Multi-function Analog Input
A2
Unit: 0.1% Unit: 0.1% Unit: 0.1% (RP input)
IW18 Main Bus Voltage
Unit: 1 V Unit: 1 V Unit: 1 V
IW19 Alarm Code (Option)
Alarm Code (Option) Alarm Code (Option) Alarm Code (Option)
IW1A Alarm Code (Option)
Alarm Code (Option) Alarm Code (Option) Alarm Code (Option)
IW1B
Reserved by the system −−−
IW1C
Multi-function Analog Input
A3
Unit: 0.1% Unit: 0.1% Reserved by the system.
