7 MECHATROLINK-II Commands
35
In the following case, a warning is generated and the command is ignored.
• If not in phase 2 or 3: Command fault (A.95)
Table 5 SEL MON1/2 Selection Range
REF1/2 Item Remarks
0 Nothing selected.
1 Output frequency
According to n035.
2 Torque reference (U-08): 0.1 %
Given only for vector control.
3 Not used.
4 Frequency reference (U-01)
According to n035.
5 Pulse train reference RP: 0.1 %
6 Main circuit current voltage: 1 V
7 Inverter alarm Refer to the Inverter alarm code list.
8 Inverter warning Refer to the Inverter warning code list.
9 Not used.
A Not used.
B INV terminal DI input
Bits 0 to 7: Terminals S1 to S7
C INV analog input FR: 0.1 %
D Not used.
E, F Not used. Always 0.
