Yealink IP Phones Auto Provisioning Guide
10
interface, the other configurations in this group can also be saved to the
<MAC>-local.cfg file (if the parameter isn't configured, the value of this parameter will
be written by “%NULL%”) in addition to the modified configuration.
#Group1: Configure line key.
linekey.X.line =
linekey.X.value =
linekey.X.pickup_value =
linekey.X.type =
linekey.X.xml_phonebook =
linekey.X.label =
#Group2: Configure programable key.
programablekey.X.type =
programablekey.X.line =
programablekey.X.value =
programablekey.X.xml_phonebook =
programablekey.X.history_type =
programablekey.X.label =
To protect against unauthorized access and tampering of sensitive information (e.g.,
login password, registration information), you can encrypt configuration files using
Yealink Configuration Encryption Tool. AES keys must be 16 characters and the
supported characters contain: 0 ~ 9, A ~ Z, a ~ z and the following special characters are
also supported: # $ % * +, - . : = ? @ [ ] ^ _ { } ~. For more information on how to encrypt
configuration files, refer to Yealink Configuration Encryption Tool User Guide .
When configuring some particular features, you may need to upload resource files to IP
phones, such as personalized ring tone file, language package file and logo file. Yealink
supplies some resource file templates for the particular features. Ask the distributor or
Yealink FAE for resource file templates. The following provides information on how to
customize resource files and specify the access URL for the resource files.
We recommend you do not edit the MAC-local CFG file. If you really want to edit
MAC-local CFG file, you can export and then edit it. For more information on how to
export this file, refer to Scenario D Import or export the local configuration file on
page 55. For more information on how to edit this file, refer to Editing Common CFG
File on page 4 and Editing MAC-Oriented CFG File on page 6.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
