Yealink SIP-T23G Quick Start Guide

3
Quick Start Guide
Yealink IP Phone – SIP-T23P & SIP-T23G
PACKAGING CONTENTS
The following items are included in your package. If you find anything missing, contact your system administrator.
Note:
• The models displayed on the phone differ from each other. The packaging content "IP Phone" listed
above takes a SIP-T23G IP phone as an example.
• We recommend that you use the accessories provided or approved by Yealink. The use of unapproved
third-party accessories may result in reduced performance.
ASSEMBLING THE DECT PHONE
1. Attach and detach the stand, as shown below:
a) Attach the stand:
Note:
• The hook switch tab has a lip which allows the handset to stay on-hook when the IP phone is mounted
vertically.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
