Yealink IP Phones Auto Provisioning Guide
22
The following figure shows a portion of the MAC-Oriented CFG file:
The following table lists guidelines you need to know when editing the MAC-Oriented CFG file:
Item
Guidelines
#
The line beginning with “#” is considered to be a comment.
#!version:1.0.0.1
It must be placed in the first line.
Do not edit and delete.
Filename
The filename matches the MAC address of your phone.
Line formats and
Rules
Each line must use the following format and adhere to the following
rules:
Configuration Parameter = Valid Value
 Separate each configuration parameter and value with an equal
sign.
 Set only one configuration parameter per line.
 Put the configuration parameter and value on the same line, and
do not break the line.
 The [$MODEL] can be added to the front of configuration
parameter to specify the value for specific phone groups.
$MODEL represents the phone model. The valid phone models
are: VP59, T58, CP960, T54W, T54S, T53W, T53, T52S, T48G,
T48S, T46G, T46S, T42G, T42S, T41P, T41S, T40P, T40G, T29G,
T27G, T23P, T23G, T21P_E2, T19P_E2 and CP920. Multiple phone
models are separated by commas. For example, [T46S, T23G]. It
is only applicable to IP phones (except
W53P/W60P/CP930W-Base) running firmware version 83 or
later.

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
