Yealink SIP-T58A Auto Provisioning Guide

Provisioning Yealink IP Phones
7
Provisioning Yealink IP Phones
This section provides instructions on how IP phones interoperate with provisioning server for
auto provisioning, and shows you the auto provisioning process and the four major tasks to
provision the phones. It will help users who are not familiar with auto provisioning to
understand this process more easily and quickly.
Interoperating with Provisioning Server
When IP phones are triggered to perform auto provisioning, they will request to download the
boot files and configuration files from the provisioning server. During the auto provisioning, the
IP phone will download and update configuration files to the phone flash.
The following figure shows how the IP phone interoperates with the provisioning server:

Yealink SIP-T58A Specifications

General

Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Operating system version	5.1.1
Operating system installed	Android
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Bluetooth	No
Security algorithms	SRTP
Networking standards	IEEE 802.1x
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv4/IPv6, UDP/TCP/DNS-SRV
USB 2.0 ports quantity	2
Voice codecs	G.711Mu, G.711a, G.722, G.722.1, G.722.1C, G.723, G.726, G.729ab, iLBC
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Front camera resolution (numeric)	2 MP
Base station keys	27
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
Power consumption (typical)	1.9 W
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	220 mm
Width	259.4 mm
Height	239 mm
Package depth	293 mm
Package width	324 mm
Package height	128 mm
