Connect Your PBX
Connect your PBX to the local network, and connect telephony lines to the PBX.
1. Connect your PBX to the network.
Connect one end of an Ethernet cable to the LAN port of your PBX, and the other end
to any port of your company’s LAN switch/router.
2. Power on your PBX.
Plug the provided power cord into the power inlet of the PBX, and the other end to a
standard electrical wall socket.
Wait for the system to boot up till the SYSTEM LED starts to blink.
3. Connect your PBX to the telephony lines.
Note: Connect BRI/PSTN/analog phone/fax machine to the corresponding port
based on the color of port indicator.
RJ11 Port Operation
FXS Connect one end of a RJ11 phone cable to the port. Connect
the other end to an analog phone or fax machine.
FXO Connect an RJ11 cable to the FXO port. Connect the other
end to a PSTN line.
BRI Connect one end of the cable provided by the ISDN BRI
provider to the BRI port. Connect the other end to the equip-
ment of ISDN provider.
E1/T1/J1 Port Operation
E1/T1/J1 Connect one end of the E1/T1/J1 cable to the E1/T1/J1 port.
Connect the other end to the E1/T1/J1 Provider’s equipment.
Note: The operation is ONLY available for P560 and
P570.
To Next Page
