Hardware Overview
TA1600 Hardware Overview
TA1600 front panel
Table 3.
No. Feature Description
① Reset Button
Press and hold for 7 seconds to reset to factory defaults.
Note:
Do NOT press this button for a long time, or the sys
tem would break down.
② Power LED
Indicates the power status.
• On: The power is switched on.
• Off: The power is switched off.
③ RUN LED
Indicates the system status.
• Blinking: The system is working properly.
• Not Blinking/Off: The system goes wrong.
④ WAN Port 10/100 adaptive RJ45 Ethernet port.
⑤ LAN Port 10/100 adaptive RJ45 Ethernet port.
⑥ FXS Ports Status Indicates the FXS port status.
• Solid green: The port is idle or no line is connected to
the port.
• Green light blinking: There is a call reaches the port or
the port is busy in a call.
