IM 01E21A03-01EN
4
<2. Explosion Protection Type>
4
Remote Sensor
Explosionproof
(Explosion Protection Code: FF2)
• Type of Protection:
CL I/II/III GP ABCDEFG
IS CL I GP ABCD
T6...T3
• Enclosure: Type 4X
• Ambient Temperature:
See Table 2.1 and Table 2.2.
• Process Temperature:
See Table 2.1 and Table 2.2.
• Um: 250 V
• Maximum Working Pressure:
Read “Fluid Temperature and Pressure”
Remote Transmitter
Explosionproof
(Explosion Protection Code: FF2)
• Type of Protection:
CL I/II/III GP ABCDEFG
• Enclosure: Type 4X
• Ambient Temperature: –40°C to +60°C
• Temperature class: T6
• Power Supply:
100 to 240 Va.c. (50/60 Hz) / 100 to 120 Vd.c.
24 Va.c. (50/60 Hz) / 24 Vd.c.
• Current I/O: 4 to 20 mA, 32 Vd.c. max.
• Digital I/O: 30 Vd.c. max., 200 mA max.
• Fieldbus I/O: 32 Vd.c. max., 15 mA max.
Explosionproof with Output IS Circuit
(Explosion Protection Code: FJ2 and FT2)
• Type of Protection
CL I/II/III GP ABCDEFG
AIS CL I/II/III GP ABCDEFG
• Enclosure: Type 4X
• Ambient Temperature: –40°C to +60°C
• Temperature class: T6
• Power Supply:
100 to 240 Va.c. (50/60 Hz) / 100 to 120 Vd.c.
24 Va.c. (50/60 Hz) / 24 Vd.c.
• Control Drawing: DIE016-A92
Table 2.1 Temperature Ratings
Model Size
Process
Connection
Lining
Temperature Table
Integral
Flowmeter
Remote
Sensor
AXG002, AXG005,
AXG010, AXG015
2.5 to 15 mm
(0.1 to 0.5 in.)
Wafer, Flange PFA Lining Table A Table C
AXG025, AXG032,
AXG040, AXG050,
AXG065, AXG080,
AXG100, AXG125
25 to 125 mm
(1 to 5 in.)
Wafer, Flange PFA Lining
Table B
[Table J]*
1
Table D
[Table J]*
1
AXG150, AXG200,
AXG250, AXG300,
AXG350, AXG400
150 to 400 mm
(6 to 16 in.)
Wafer, Flange PFA Lining Table A Table C
AXG015, AXG025,
AXG032, AXG040,
AXG050, AXG065,
AXG080, AXG100,
AXG125
15 to 125 mm
(0.5 to 5 in.)
Clamp, Union,
Butt Weld Joint
PFA Lining Table E Table F
AXG002, AXG005,
AXG010, AXG015,
AXG025, AXG040,
AXG050, AXG080,
AXG100, AXG150,
AXG200
2.5 to 200 mm
(0.1 to 8 in.)
Wafer Ceramics Tube Table G Table H
*1: When process connection code EA4 is specied, temperature table is changed to table in [ ].
The process connection code EA4 is available for AXG025, AXG040, AXG050, AXG080, and AXG100.
