YOKOGAWA Daqstation DX2000 User Manual

3-22
IM 04L42B01-01E
SetupItems
• Alarmaction>Annunciatormode
Select On to use the annunciator function.
• Alarmaction>Sequence
Select the annunciator sequence. For details about the annunciator sequence, see
“Explanation” in this section.
Setting Description
ISA-A-4 A no lock-in sequence.
ISA-A A lock-in sequence.
ISA-M A double lock-in sequence.
• Alarmaction>Timeoffcolor
The window display color when no alarms are activated. You can select white or
green.
• LevelsandColors
See section 3.7.
• Annunciatorposition
The position of the annunciator window. See the explanation for the next item.
• Annunciatorposition>On/Off
Set the annunciator position that you want to use to On.
Starting with 1, consecutively set all annunciator positions that you want to use to On.
After a position has been set to Off, all of the positions after it will also be turned off
even if they are set to On. The annunciator display changes depending on how many
annunciator windows you use. For details, see “Explanation.”
• Annunciatorposition>Channel,Level
You can assign alarms to annunciator windows by specifying channel numbers and
alarm levels.
You can set Level to 1, 2, 3, 4, or All. If you select All, all of the alarms in the specified
channel are assigned to the specified window.
• Annunciatorposition>CommenttxtblockNo.
You can select a text string (label) to display in the annunciator window by selecting a
comment text block number.
For information about how to set comment text blocks, see section 5.19.
3.12UsingtheAlarmAnnunciatorFunction(Releasenumber3orlater)
