6.9 Saving/LoadingtheSetupData
Save the setup data to the external storage medium or load the setup data from the
external storage medium.
Procedure
• SavingtheSetupData
1.
Carry out the procedure below to show the display.
Press MENU (to switch to setting mode), and select the File tab > Savesettings.
Press the CF or USB soft key
*
, and then press DISP/ENTER.
* When a CF card and a USB flash memory (/USB1 option) are being used.
2.
Set the file name. (Up to 32 characters,
A a # 1
)
Symbols that can be used: #, %, (, ), +, -, ., @, °, and _.
Strings that cannot be used: AUX, CON, PRN, NUL, CLOCK, COM1 to COM9, and LPT1 to LPT9.
To cancel the operation, press ESC.
3.
Press DISP/ENTER.
The setup data is saved.
