5.12 UsingtheCircularDisplay
Use a circular display in place of the trend display.
For a description of the function, see section 1.3.
SetupScreen
• CircularDisplay
Press MENU (to switch to setting mode), hold down FUNC for 3 s (to switch to basic
setting mode), and select the Environment tab > View,Message,Input,Tag.
• TimeperRevolution
Press MENU (to switch to setting mode), and select the Menu tab > Display>
Circular/Saveinterval.
