Explanation
• SetupDataFile
 OnDXswithoutthe/AS1advancedsecurityoption
• Thesetupdatafileextensionis.PDL.
• Themaximumsetupdatafilesizeisapproximately250KB.
• Thefollowingsettingsarealsosaved.
• Currentmonitordisplayconditions
• Defaultdisplayregistrationdata
• Favoritekeyregistrationdata
 OnDXswiththe/AS1advancedsecurityoption
• Thesetupdatafileextensionis.PEL.
• Themaximumsetupdatafilesizeisapproximately250KB.
• Thefollowingsettingsarealsosaved.
• Currentmonitordisplayconditions
• Defaultdisplayregistrationdata
• Favoritekeyregistrationdata
• LoadingSetupData
 OnDXswithoutthe/AS1advancedsecurityoption
• Onlythesetupdataofthesettingmodeisloadedinthesettingmode.However,
settings that contradict the setup data of the basic setting mode are not loaded.
• Themonitordisplayconditions,defaultdisplay,andfavoritekeysarealsoloaded.
• Ifthecontentsoftheloadedsetupdataisinvalid,checktheerrorlog(seesection
4.9).
• Operationsthroughkeys,communications,andremotecontrolinputarenot
executed while the setup data is being loaded.
 OnDXswiththe/AS1advancedsecurityoption
• Ifthesetupdataischangedbyloadingnewsetupdata,theoriginalsetupfile
is automatically saved to CF card. If no CF card is inserted, an error message
appears and the operation cannot be completed.
• Allsettings,Logininfoonly,andOthersettings
The“Loadsettings”
option
Description
All settings The DX loads all setting mode and basic setting mode settings.
However, the login password is not loaded. The password is set
to the default password.
Login info only The DX only loads the login settings. However, the login
password is not loaded. The password is set to the default
password.
Other settings The DX loads all setting except for the login settings.
• Insettingmode,onlythesettingmodesettingsareloaded.However,settingsthat
contradict the basic setting mode settings are not loaded.
• Inanycase,theoptionto“Loadsettings”alsoloadsmonitordisplayconditions,the
default display, and favorite keys.
• Iftheloadedsetupdataisnotapplied,checktheerrorlog(seesection4.9).
Note
• Whileloadingthesetupdata,keyoperations,operationsviacommunications,and
operations via remote input are not available.
• Whileloadingthesetupdata,actionsoftheEventActionfunctionaredisabled.Events
occurring while loading the setup data are ignored.
6.9Saving/LoadingtheSetupData
