YOKOGAWA Daqstation DX2000 User Manual

10-3
IM 04L42B01-01E
Using External Input Channels (/MC1 Option)
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
SetupItems
• SettingtheInput
The measured values of external instruments are loaded using the Modbus client or
Modbus master function to be used as external input channel inputs.
For the setup procedure, see the Communication Interface User’s Manual,
IM04L41B01-17E.
• First-CH/Last-CH
Select the target channels. Channel numbers are 201 to 440.
• Ext.range>On/Off
Select On to use the external input channel.
• Ext.range>SpanLowerandSpanUpper
Measurement range.
Selectable range of values: –30000 to 30000
Decimal place: Down to four digits to the left of the decimal point
10.1SettingExternalInputChannels
