Joule Integral (I
2
t) Waveform Display (I
2
t(Math1))
ON: The Joule integral (I
2
t) waveform is displayed. Computation settings (MATH/REF) become invalid.
OFF: The Joule integral (I
2
t) waveform is not displayed. Computation settings (MATH/REF) are valid.
Auto Scaling (Auto Ranging)
Executes auto scaling. Use this feature when the waveform amplitude changes greatly and the waveform is
difficult to view.
You can also set the display range by specifying the vertical center I
2
t value (Center) of the display area and the
I
2
t value per division (Sensitivity).
In Joule integral measurement, you can compute statistics in three different modes: Continuous, Cycle, and
History.
