YOKOGAWA MVAdvanced MV1000 User Manual

2-5
Troubleshooting
SM MV1000-01E
1
2
3
4
5
6
7
No. Phenomenon
Action
Description
Refer to Chapter 6
Check Adjust Replace
*1
Part Name
MV1000 MV2000
Page Item Page Item
8
External media
functioning
abnormally

Is the memory medium (CF card)
working normally?
- - - - -
 
Check the FFC
*3
for the MEDIA PBA
*2
(whether pulled out or damaged)
- - - - -

MEDIA BOARD ASSEMBLY - 6-2 - 6-10 -

SUB BOARD ASSEMBLY
Sub PCB Assembly
6-3 5 6-12 13

MAIN BOARD ASSEMBLY Main PBA 6-3 4 6-12 11
9
Abnormal
communication

Check communication settings - - - - -

Check communication wiring/cables
(whether pulled out or damaged)
- - - - -

POW TERM & COMM BOARD
ASSEMBLY
I-PWR Terminal
24V-Power Terminal
Power Terminal
6-4 8 6-14
3

MAIN BOARD ASSEMBLY Main PBA 6-3 4 6-12 11
10
USB operation
abnormal

Are connected USB devices (USB
memory and USB keyboard)
operating normally?
- - - - -
 
Check the FFC
*3
for the MEDIA PBA
*2
(whether pulled out or damaged)
- - - - -

MEDIA BOARD ASSEMBLY
(front panel)
Media CF PBA 6-2 - 6-10 -

POW TERM & COMM BOARD
ASSEMBLY (rear panel)
I-PWR Terminal
24V-Power Terminal
Power Terminal
6-4 8 6-14
3

SUB BOARD ASSEMBLY
Sub PCB Assembly
6-3 5 6-12 13

MAIN BOARD ASSEMBLY Main PBA 6-3 4 6-12 11
*1:
The table shows only the specific parts that must be replaced. When actually carrying out
replacement, the entire assembly that contains a part may have to be replaced.
*2:
Printed Board Assembly
*3: Flexible Flat Cable
2.2 Troubleshooting Checklist
