ExplicitMessage
An Explicit message is a point-to-point, request/response-type communication.
Communication using Explicit messages are only supported for PCCC.
SystemConfigurationonPLC
Use the configuration tool to code an Explicit message as an MSG instruction in the
control logic. In the MSG instruction, set all the information including a target device,
target register, and read/write. Download the created control logic to a PLC and execute
it.
On the recorder the data count to be accessed per MSG instruction should be 100 or less.
InCaseofPLC-2,PLC-5,andSLC
• Commands
When creating an MSG instruction, specify a command. The recorder supports the
following commands:
TargetPLC Command name
PLC-2 PLC2 Unprotected Read/Write
PLC-5 PLC5 Word Range Read/Write
PLC5 Typed Read/Write
SLC SLC Typed Read/Write
• Specificationofdatatobeaccessed
Specify which of the data in the recorder should be accessed. The PLC-2, PLC-5, and
SLC manage data to be accessed in units of “files.”
Command:PLC2UnprotectedRead/Write
Datatobeaccessed Filenumber
Datatype:INT16
Type Number
Input/Output channel
(GX/GP main unit)
(GM main unit)
0001 1000
• • • • • •
0050 1049
0101 1050
• • • • • •
0150 1099
0201 1100
• • • • • •
0250 1149
0301 1150
• • • • • •
0350 1199
0401 1200
• • • • • •
0450 1249
0501 1250
• • • • • •
0550 1299
0601 1300
• • • • • •
0650 1349
0701 1350
• • • • • •
0750 1399
0801 1400
• • • • • •
0850 1449
0901 1450
• • • • • •
0950 1499
Continued on next page
