AssumptionofExplanation
The explanation in this manual assumes that the recorder is connected via communications
with Rockwell Automation’s Programmable Logic Controller (PLC) of the Allen-Bradley
brand.The basic items for this configuration are explained. For the operation procedures of
Rockwell Automation products, see the user’s manuals of these products.
This manual is intended for those who have used an Allen-Bradley PLC and EtherNet/IP.
RecorderVersionDescribedinThisManual
The contents of this manual correspond to the GX/GP with release number 4 (see the
STYLE S number) and style number 2 (see the STYLE H number) and the GM10 with
release number 4 (see the STYLE S number) and style number 1 (see the STYLE H
number).
Edition Product Explanation
1 GX/GP: Version 2.01 and later —
2 GX/GP: Version 2.01 and later Describes the GM.
GM: Version 2.02 and later
3 GX/GP: Version 3.01 and later The number of math channels has been increased
(GX20-2,GP20-2: 200 channels)
GM: Version 3.01 and later
4 GX/GP: Version 4.01 and later Describes the PID control module.
GM: Version 4.01 and later
5 GX/GP: Version 4.06 and later Describes of the QR code has been added.
GM: Version 4.06 and later Improvements to explanations.
6 GX/GP: Version 4.07 and later Loading alarm information (Explicit message, I/O
message)
Addition of a recorder control function (Explicit
message)
GM: Version 4.07 and later
