8
IM 04L51B01-18EN
Explicit Message
Datatobeaccessed Filenumber
Datatype:INT16
Type Number
Input/Output channel
(Continuous channel data
area)*
0001 4500
• • • • • •
0010 4509
0101 4510
• • • • • •
0110 4519
0201 4520
• • • • • •
0210 4529
0301 4530
• • • • • •
0310 4539
0401 4540
• • • • • •
0410 4549
0501 4550
• • • • • •
0510 4559
0601 4560
• • • • • •
0610 4569
0701 4570
• • • • • •
0710 4579
0801 4580
• • • • • •
0810 4589
0901 4590
• • • • • •
0910 4599
Computation channel A001 5000
• • • • • •
A200 5199
Communication channel
(Read/Write)
C001 6000
• • • • • •
C500 6499
“• • •” stands for data in numerical order.
* The “continuous channel data area” is a special area that enables continuous reading by limiting
the number of channels of each module to 10.
For only the I/O channels on a GX/GP main unit or I/O channels on a GM main unit, this area
can be used to read data consecutively.
