2-7
TI 05C01E02-01E 1st Edition : Oct. 31, 2001-00
● Terminal Cover
Model Description
L4000FB
Terminal cover for models UT130 and UT150 (1 set)
T9115YE
Terminal cover for model UT152 (1 piece)
T9115YD
Terminal cover for model UT155 (1 piece)
● Mounting Bracket
Model Description
L4000FA
Mounting bracket for models UT130 and UT150 (1 piece)
T9115NK
Mounting bracket for model UT152 (1 set)
T9115NL
Mounting bracket for model UT155 (1 set)
■ Measured Input Type, Scaling and Direct/Reverse Action can be Speci-
fied on Ordering
Measured input type, displayed scale at voltage input, and direct/reverse action for the
temperature controller can be specified on ordering.
Items to specify Description
Measured
input type
Specify "1" to "7", "12", "13", and "15 to "19" for UT130.
Specify "1" to "23" for UT150/UT152/UT155.
If no input type is specified at the time of ordering, the temperaturecontroller
is shipped with the parameter set to OFF (unidentified).
In this case, set the input type on customer side.
See "4.1 Setting Measured Input Type and Scale (Setting First)" for details.
Scaling
(at voltage input)
Direct/reverse
action
The displayed scale can be specified when specifying "20" to "23"
for UT150/UT152/UT155. If no scaling is specified, the temperature controller
is shipped with the parameter set to "0.1 to 100.0".
Specify "1" for direct action. If no action is specified, the temperature
controller is shipped with the parameter set to "0" (reverse action).
To Next Page
