Figure 5-4 PAS level display interface
5.6 Battery level display
The Battery level is shown as 5 bars. When the battery is full charged, all of the 5 bars lighten up. When the battery is
fully depleted, the bar will begin to flash, warning the user to charge the battery as soon as possible.
Full power Four bars power Three bars power Two bars power One bar power
Figure 5-5 Battery Level Display Interface
5.7 Error code display
If there is a fault occurs in the electronic system of the electric bicycle, the display will automatically show an error
code, see Schedule 1 for a detailed definition of the error code.
Figure 5-6 Error Code Display
When the error code appears on the display, please troubleshoot the problem in time, the electric bicycle will
not be able to drive normally after the problem occurs.
6. Personalized parameter settings
Each setting needs to be done with the bicycle stationary.
The personalized parameter setting procedure is as follows:
