Name of Parts/Quick Start Guide
A-LCD: Display all the settings of controller.
B-2.5MM Shutter release interface: Wireless shutter release
function(P.16).
C-AF assist beam emitter: (P.14)
D-PC interface: Input the flash sync signal(P.15).
E-USB interface: Connected to the computer to update the
firmware (P.19).
F- button: Flash mode setting.
G-GR/* button: Short press to move the arrow to set flash group
or other parameters; Long press to get different functions int
different modes.
H-TEST button: Long press to wake the flash up, loosen to test
the flash(P.12).
I-Select/Set button group: Multifunction button group, including
the [UP] [DOWN] [LEFT] [RIGHT] and [OK] buttons.
J-SYNC/FN button: Short press for flash shutter sync mode
setting(P.11), long press for C.FN setting (P.14).
K-ZOOM/CH button: short press for zoom setting (P.11), long
press for channel setting(P.7) .
L-Power switch: Slide to ON for power on.
M-Status indicator : The green light will bright when in
communication; while the red light will bright when in triggering
(or shutter releasing).
N-Locking ring and locking pin
O-Hot shoe Mounting foot and contacts
P-Battery compartment and battery cover
To Next Page
