18
YORK REF. FAC. REF. DESCRIPTION QTY.
56030A00 A CONSOLE 1
56030A01 A-1 SCREW (M5X14L) 4
56030B00 B FRAME 1
56030B01 B-1 HANDLEBAR HOLDER 1
56030B02 B-2 SCREW (M4X10L) 2
56030B03 B-3 NUT (M16*5L) 1
56030B04 B-4 SPROKET-WHEEL (14-TOOTH) 1
56030B05 B-5 BEARING 6001RS 1
56030B06 B-6 RUBBER BUSHING 1
56030B07 B-7 BEARING 6003RS 1
56030B08 B-8 FAN AXLE (192L) 1
56030B09 B-9 FLAT WASHER (_12X_19X1T) 1
56030B10 B-10 C-CLIP _12 2
56030B11 B-11 PLUG 3
56030B12 B-12 SCREW (M5XP0.8X16L) 18
56030B13 B-13 ALLEN BOLT (M6XP1.0X75L) 1
56030B14 B-14 ROLLING WHEEL 1
56030B15 B-15 NYLON NUT (M6) 1
56030B16 B-16 CABLE, UPPER 1
56030B17 B-17 PULSE WIRE 1
56030B18 B-18 DC WIRE 1
56030B19 B-19 SERVOMOTOR W/LOWER CABLE 1
56030C00 C FOLDABLE FIXING SUPPORT 1
56030C01 C-1 CONNECTING ROD (_13*155L) 1
56030C02 C-2 RUBBER STOP 1
56030P06 P-6 FLAT WASHER (_8.5X_18X2T) 2
56030C03 C-3 SHOULDER SCREW (M8*25L) 2
56030D00 D FOLDABLE FRONT POST 1
56030D01 D-1 FRONT POST END CAP 1
56030D02 D-2 SCREW (M4X12L) 1
56030P06 P-6 FLAT WASHER (_8.5X_18X2T) 4
56030C03 C-3 SHOULDER SCREW (M8*25L) 2
56030E00 E AIR FAN ASSEMBLY 1
56030E01 E-1 AIR FAN COVER, LEFT 1
56030E02 E-2 AIR FAN COVER, RIGHT 1
56030E03 E-3 SCREW (M4X25L) 6
56030E04 E-4 MAGNETIC RESISTANCE SET GUIDE PLATE 1
56030E05 E-5 FIXING BRACKET 1
56030E06 E-6 SCREW (M5XP0.8X20L) 4
56030E07 E-7 MAGNETIC RESISTANCE SET 1
56030E08 E-8 SCREW (M4*8L) 6
56030E09 E-9 SCREW (M3X8L) 4
56030E10 E-10 SPRING (_0.9*60T) 2
56030E11 E-11 SCREW (M8XP1.25X20L) 4
56030E12 E-12 FLAT WASHER (_8X_16X2T) 4
56030E13 E-13 AIR FAN COVER FIXING PLATE 1
56030E14 E-14 SCREW (M6XP1.0X22L) 4
56030E15 E-15 MAGNET_15X5T 3
56030E16 E-16 RESISTANCE DISC 1
56030E17 E-17 BUSHING (_6*_12*5L) 4
56030E18 E-18 SCREW (M5XP0.8X14L) 12
56030E19 E-19 AIR FAN FIXING DISC 1
56030E20 E-20 NYLON NUT (M5) 8
56030E21 E-21 AIR FAN 1
56030E22 E-22 ONE WAY BEARING (_32*_20*17L) 1
56030E23 E-23 BEARING 6001RS 2
56030E24 E-24 PIVOT BUSHING 1
56030E25 E-25 NYLON NUT (M6) 4
56030E26 E-26 AIR VENT 1
56030E27 E-27 PIVOT BUSHING FIXING PLATE 1
56030E28 E-28 PLASTIC WASHER (_28) 1
56030E29 E-29 AIR FAN COVER PLUG 1
56030E30 E-30 SENSOR WIRE 2
56030E31 E-31 MAGNET FIXED BOARD 1
56030F00 F REAR STABILIZER 1
56030F01 F-1 RUBBER STOP 1
56030F02 F-2 CONNECTING ROD (_13*67.5L) 1
56030F03 F-3 NUT (M8) 1
56030F04 F-4 REAR STABILIZER END CAP 1
56030F05 F-5 SCREW (M8XP1.25X12L) 3
YORK REF. FAC. REF. DESCRIPTION QTY.
56030G00 G SLIDING SEAT ASSEMBLY 1
56030G01 G-1 SEAT FIXING BRACKET 1
56030G02 G-2 NUT (M6) 6
56030G03 G-3 SEAT ROLLING WHEEL SET(INCL. G-2~G-5) 6
56030G04 G-4 BUSHING (_6.2*_9*3T) 6
56030G05 G-5 SCREW (M6XP1.0X22L) 6
56030G06 G-6 SEAT 1
56030G07 G-7 SCREW (M6XP0.8X15L) 4
56030H00 H SEAT RAIL ASSEMBLY 1
56030H01 H-1 SEAT RAIL 1
56030H02 H-2 WIRE PLUG 1
56030H03 H-3 WIRELESS RECEIVER FIXER 1
56030H04 H-4 WIRELESS PULSE RECEIVER 1
56030H05 H-5 SCREW (M4X8L) 2
56030H06 H-6 SCREW (M5XP0.8X8L) 2
56030I09 I-9 CARRIAGE BOLT (M8XP1.25X55L) 2
56030I02 I-2 FLAT WASHER (_8X_25X2T) 4
56030I03 I-3 ACORN NUT (M8) 2
56030I04 I-4 SCREW (M8XP1.25X20L) 2
56030I05 I-5 SPRING WASHER (_8.1*_12.3*2.1T) 2
56030I06 I-6 LOCKING KNOB (M12*65L) 1
56030I00 I HARDWARE PACK 1
56030I01 I-1 CARRIAGE BOLT (M8XP1.25X55L) 2
56030I02 I-2 FLAT WASHER (_8X_25X2T) 10
56030I03 I-3 ACORN NUT (M8) 4
56030I04 I-4 ALLEN BOLT (M8XP1.25X20L) 6
56030I05 I-5 SPRING WASHER (_8.1*_12.3*2.1T) 2
56030I06 I-6 LOCKING KNOB (M12*65L) 1
56030I07 I-7 BOX SPANNER 1
56030I08 I-8 ALLEN KEY 2
56030I09 I-9 CARRIAGE BOLT (M8XP1.25X55L) 2
56030J00 J FRONT STABILIZER 1
56030J01 J-1 FRONT FOOT 1
56030J02 J-2 END CAP W/TRANSPORT WHEEL, LEFT 1
56030J03 J-3 END CAP W/TRANSPORT WHEEL, RIGHT 1
56030J04 J-4 SCREW (3/16"X3/4") 2
56030I01 I-1 CARRIAGE BOLT (M8XP1.25X55L) 2
56030I02 I-2 FLAT WASHER (_8X_25X2T) 2
56030I03 I-3 ACORN NUT (M8) 2
56030K00 K ADAPTOR 9V, 1300MA 1
56030L00 L HANDLEBAR ASSEMBLY 1
56030L01 L-1 CHAIN 1
56030L02 L-2 HANDLEBAR FOAM GRIP 1
56030L03 L-3 HANDLEBAR END CAP 2
56030L04 L-4 CHAIN FIXING ROD 1
56030M00 M CHAIN PULLEY FIXER 1
56030M01 M-1 C-CLIP (_8) 1
56030M02 M-2 FIXING SLEEVE (_8*19L) 1
56030M03 M-3 SCREW (M6XP1.0X12L) 4
56030M04 M-4 FLAT WASHER (_6X_13X2T) 4
56030M05 M-5 PULLEY (_42*15L) 4
56030M06 M-6 BUSHING (_10*_14*8.5L) 2
56030M07 M-7 FIXING AXLE (_10*60L ) 1
56030M08 M-8 BUSHING (_10*_14*11L) 1
56030M09 M-9 BEARING 6900 7
56030M10 M-10 FIXING AXLE (_10*_14*23L) 1
56030M11 M-11 PULLEY W/BEARING (_36*21L) 1
56030M12 M-12 PULLEY W/BEARING (_41*15L) 2
56030M13 M-13 C-CLIP (_10.2*1T) 5
56030M14 M-14 ALLEN BOLT (M6X12L) 2
56030M15 M-15 FIXING AXLE (_10*_14*60L) 1
56030M16 M-16 ELASTIC CORD (_8*2200MM) 1
56030L01 L-1 CHAIN 1
56030N00 N LINKAGE ROP ASSEMBLY 1
56030N01 N-1 FRONT LINKAGE ROP (M12*128L) 1
56030N02 N-2 NUT (M12*1.75* 9.5T) 1
56030N03 N-3 LINKAGE SLEEVE (M12*90L ) 1
56030N04 N-4 NUT (M12*1.75*9.5T) 1
56030N05 N-5 REAR LINKAGE ROP (M12*174.2L) 1
56030N06 N-6 FLAT WASHER (_8X_19X2T) 2
Part list
