York 41HP AHR18B User Manual

661693-UIM-E-1212
Johnson Controls Unitary Products 11
TABLE 8: ELECTRICAL DATA FOR SINGLE SOURCE POWER SUPPLY - 208/230-3-60
Air Handler Models
Heater
Models
Heater
Amps
@ 240V
Field Wiring
Min. Circuit Ampacity
MOP
1
Min. Wire Size (AWG)
2
208V 230V 208V 230V 208V 230V
AHR24B
6HK06501025 23.1 26.8 30.7 30 35 10 10
6HK06501525 34.6 39.2 45.0 40 45 8 8
AHR30B
AHR42C
6HK06501025 23.1 28.8 32.7 30 35 10 8
6HK06501525 34.6 41.2 47.0 45 50 8 8
AHR36B
AHR48D
6HK06501025 23.1 28.8 32.7 30 35 10 8
6HK06501525 34.6 41.2 47.0 45 50 8 8
6HK06501825 41.6 48.8 55.8 50 60 8 6
6HK16502025
3
46.2 53.8 61.5 60 70 6 6
AHR60D
6HK06501025 23.1 28.8 32.7 30 35 10 8
6HK06501525 34.6 41.2 47.0 45 50 8 8
6HK06501825 41.6 48.8 55.8 50 60 8 6
6HK16502025
3
46.2 53.8 61.5 60 70 6 6
6HK16502525
3
57.7 66.3 75.9 70 80 4 4
1. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse.
2. Stated sizes are for 75°C, copper wire only. If wire other than non-plated, 75°C ambient, copper wire is used, consult applicable tables of the NEC and local codes.
3. The 20kW and 25kW heater models (6HK16502025 and 6HK16502525) come with circuit breakers standard. Single source power MCA and MOP requirements are
given here only for reference if used with field installed single point power modification.
TABLE 9: ELECTRICAL DATA FOR MULTI-SOURCE POWER SUPPLY: 208/230-3-60
Air Handler Models
Heater
Models
Total Heater
Amps
@ 240V
Min. Circuit Ampacity
MOP
1
Min. Wire Size (AWG)
2
208V 230V 208V 230V 208V 230V
Circuit Circuit Circuit
1st
3
2nd
1st
3
2nd
1st
3
2nd
1st
3
2nd
1st
3
2nd
1st
3
2nd
AHR36B
AHR48D
6HK16502025 46.2 28.8 25.0 32.6 28.9 30 25 35 30 10 10 8 10
AHR60D
6HK16502025 46.2 28.8 25.0 32.6 28.9 30 25 35 30 10 10 8 10
6HK16502525 57.7 35.0 31.3 39.8 36.1 35 35 40 40 8888
1. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse.
2. Stated sizes are for 75°C, copper wire only. If wire other than non-plated, 75°C ambient, copper wire is used, consult applicable tables of the NEC and local codes.
3. 1st Circuit includes the blower motor amps.
TABLE 10: AIR FLOW DATA (CFM)
1
Models
Blower
Motor Speed
External Static Pressure (in. wc.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70
208 Volt
AHR18B3XH21
High
1024 1000 970 930 860 810 NA
Medium
756 731 700 670 620 550 NA
Low
557 531 495 445 375 315 195
AHR24B3XH21
High
995 970 935 900 925 795 645
Medium
820 810 780 745 695 545 485
Low
715 695 640 405 370 375 220
AHR30B3XH21
High
1380 1315 1245 1160 1075 990 885
Medium
1060 1040 1005 955 890 860 820
Low
1035 980 910 825 770 685 485
AHR36B3XH21
High
1410 1335 1270 1190 1110 990 820
Medium
1215 1170 1115 1050 935 850 740
Low
950 935 895 855 NA NA NA
AHR42C3XH21
High
1800 1725 1645 1545 1360 1200 1050
Medium
1535 1480 1415 1280 1155 1010 870
Low
1225 1195 1095 1025 925 825 680
Continuation on Page 12.
