York AFFINITY BHZ - Performance Data; Cooling Capacities

718419-YTG-D-0613
12 Johnson Controls Unitary Products
115°F 125°F
600
77 22.6 2.3 12.1 9.2 6.4 - - - 22.5 2.6 12.4 9.5 6.7 - - -
72 20.6 2.3 16.0 13.1 10.3 7.4 - - 19.7 2.5 15.7 12.8 10.0 7.1 - -
67 18.6 2.3 18.6 17.0 14.1 11.3 8.4 - 16.9 2.5 16.9 16.1 13.3 10.4 7.6 -
62 17.5 2.3 17.5 17.5 16.0 13.2 10.3 7.5 15.9 2.5 15.9 15.9 14.7 11.8 9.0 6.1
57 18.0 2.3 18.0 18.0 15.6 12.7 9.9 7.0 16.7 2.5 16.7 16.7 13.9 11.1 8.2 5.4
700
77 22.6 2.4 15.8 10.5 6.7 - - - 22.3 2.7 16.8 11.1 7.0 - - -
72 20.6 2.4 17.5 14.2 10.8 7.4 - - 19.5 2.7 17.3 13.9 10.5 7.2 - -
67 18.6 2.4 18.6 17.8 14.9 11.5 8.1 - 16.7 2.6 16.7 16.7 14.0 10.7 7.3 -
62 17.4 2.4 17.4 17.4 16.8 13.5 10.1 6.7 15.8 2.6 15.8 15.8 15.5 12.1 8.8 5.4
57 18.0 2.4 18.0 18.0 16.4 13.0 9.6 6.3 16.5 2.6 16.5 16.5 14.7 11.4 8.0 4.6
800
77 22.6 2.5 19.6 11.8 7.0 - - - 22.0 2.8 21.2 12.6 7.4 - - -
72 20.6 2.5 19.1 15.2 11.3 7.4 - - 19.3 2.8 18.9 15.0 11.1 7.2 - -
67 18.6 2.5 18.6 18.6 15.6 11.7 7.8 - 16.5 2.7 16.5 16.5 14.8 10.9 7.0 -
62 17.4 2.5 17.4 17.4 17.7 13.8 9.9 6.0 15.6 2.7 15.6 15.6 15.6 12.4 8.6 4.7
57 18.0 2.5 18.0 18.0 17.2 13.3 9.4 5.5 16.3 2.8 16.3 16.3 15.5 11.6 7.7 3.8
900
72 20.7 2.6 20.0 16.2 11.8 7.3 - - 19.3 2.9 19.3 15.9 11.5 7.0 - -
67 18.7 2.6 18.7 18.7 16.2 11.8 7.3 - 16.5 2.8 16.5 16.5 15.3 10.8 6.4 -
62 17.5 2.6 17.5 17.5 17.7 13.2 8.8 4.4 15.6 2.8 15.6 15.6 15.6 11.5 7.1 2.7
57 18.1 2.6 18.1 18.1 17.7 13.3 8.9 4.4 16.3 2.8 16.3 16.3 15.9 11.5 7.0 2.6
1000
72 20.9 2.7 20.9 17.1 12.2 7.2 - - 19.3 2.9 19.3 16.8 11.8 6.9 - -
67 18.9 2.7 18.9 18.9 16.8 11.8 6.8 - 16.5 2.9 16.5 16.5 15.8 10.8 5.8 -
62 17.7 2.6 17.7 17.7 17.7 12.7 7.7 2.8 15.6 2.9 15.6 15.6 15.6 10.6 5.6 0.7
57 18.2 2.6 18.2 18.2 18.2 13.3 8.3 3.3 16.3 2.9 16.3 16.3 16.3 11.3 6.4 1.4
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
BHZ024 (2.0 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
