York AFFINITY BHZ - Sound Performance; BHZ Outdoor Sound Power Levels; BHQ Outdoor Sound Power Levels

718419-YTG-D-0613
58 Johnson Controls Unitary Products
Sound Performance
BHQ Outdoor Sound Power Levels
BHZ/BHQ/BHX Indoor Blower Specifications
Model
(Tons)
Motor
HP RPM Eff. SF Frame
024
(2.0)
1/2 Variable 0.8 1.0 48
030
(2.5)
1/2 Variable 0.8 1.0 48
036
(3.0)
3/4 Variable 0.8 1.0 48
042
(3.5)
3/4 Variable 0.8 1.0 48
048
(4.0)
3/4 Variable 0.8 1.0 48
060
(5.0)
1 Variable 0.8 1.0 48
Electric Heat Multipliers
Voltage
kW Capacity Multipliers
1
1. Electric heaters are rated at nominal voltage. Use this table to determine the electric heat
capacity for heaters applied at lower voltages.
Nominal Applied
240
208 0.75
230 0.92
480 460 0.92
BHZ Outdoor Sound Power Levels
Model
(Tons)
Sound Rating
1
dB (A)
1. Rated in accordance with AHRI 270 standard.
Octave Band Centerline Frequency (Hz)
125 250 500 1000 2000 4000 8000
BHZ024
(2.0)
77 64 74 71 69 65.5 58 46
BHZ030
(2.5)
77 65 66.5 72 71.5 68.5 65.5 64.5
BHZ036
(3.0)
78 67.5 67 73 73 69 64.5 61.5
BHZ042
(3.5)
77 64.5 67 71.5 72.5 69.5 64.5 59
BHZ048
(4.0)
78 65 67 72 72 69 67.5 63
BHZ060
(5.0)
85 70 72.5 79 79.5 76 73.5 73
Model
(Tons)
Sound Rating
1
dB (A)
Octave Band Centerline Frequency (Hz)
125 250 500 1000 2000 4000 8000
BHQ024
(2.0)
75 65.5 66.5 69 69.5 64 62 57
BHQ030
(2.5)
77 65 66.5 72 71.5 68.5 65.5 64.5
BHQ036
(3.0)
79 73 71.5 72 71 67 64.5 60
BHQ042
(3.5)
77 64.5 67 71.5 72.5 69.5 64.5 59
BHQ048
(4.0)
80 70 71 75 74 70 66 67
BHQ060
(5.0)
80 67 69 73.5 77 69 66.5 60
1. Rated in accordance with ARI 270 standard.
