Electrical Data
BHZ024-060 Heat Pump With/Without Electric Heat
Model
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Electric Heat Option
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA Model kW Stages Amps
BHZ024
(2.0)
208/230-1-60 12.8 60 20 1.2 4.1
None - - - 21.3 30
2NH04500506 3.8/5 1 18.1/20.8 43.9/47.3 50/50
2NH04500706 5.6/7.5 2 27.1/31.3 55.2/60.4 60/70
2NH04501006 7.5/10 2 36.1/41.7 66.4/73.4 70/80
2NE04500706 5.6 / 7.5 2 27.1 / 31.3 33.9 / 39.1 35 / 40
2NE04501006 7.5 / 10 2 36.1 / 41.7 45.1 / 52.1 50 / 60
BHZ030
(2.5)
208/230-1-60 14.7 73 23 1.2 4.1
None - - - 23.7 30
2NH04500506 3.8/5 1 18.1/20.8 46.2/49.7 50/50
2NH04500706 5.6/7.5 2 27.1/31.3 57.5/62.7 60/70
2NH04501006 7.5/10 2 36.1/41.7 68.8/75.8 70/80
2NH04501506 11.3/15 2 54.2/62.5 91.4/101.8 100/110
2NE04500706 5.6 / 7.5 2 27.1 / 31.3 33.9 / 39.1 35 / 40
2NE04501006 7.5 / 10 2 36.1 / 41.7 45.1 / 52.1 50 / 60
2NE04501506 11.3 / 15 2 54.2 / 62.5 67.7 / 78.1 70 / 80
208/230-3-60 10.4 60 16 1.2 4.1
None - - - 18.3 25
2NH04501025 7.5/10 1 20.8/24.1 44.4/48.4 45/50
2NH04501525 11.3/15 1 31.3/36.1 57.4/63.4 60/70
460-3-60 4.5 31 7 0.8 4.1
None - - - 8.5 15
2NH04501046 10 1 12 23.5 25
2NH04501546 15 1 18 31 35
BHZ036
(3.0)
208/230-1-60 15.4 83 24 1.2 6.0
None - - - 26.5 35
2NH04500506 3.8/5 1 18.1/20.8 49/52.5 50/60
2NH04500706 5.6/7.5 2 27.1/31.3 60.3/65.5 70/70
2NH04501006 7.5/10 2 36.1/41.7 71.6/78.5 80/80
2NH04501506 11.3/15 2 54.2/62.5 94.2/104.6 100/110
2NE04500706 5.6 / 7.5 2 27.1 / 31.3 33.9 / 39.1 35 / 40
2NE04501006 7.5 / 10 2 36.1 / 41.7 45.1 / 52.1 50 / 60
2NE04501506 11.3 / 15 2 54.2 / 62.5 67.7 / 78.1 70 / 80
208/230-3-60 11.5 77 18 1.2 6.0
None - - - 21.6 30
2NH04501025 7.5/10 1 20.8/24.1 47.6/51.6 50/60
2NH04501525 11.3/15 1 31.3/36.1 60.7/66.7 70/70
460-3-60 5.1 35 8 0.8 6.0
None - - - 10.1 15
2NH04501046 10 1 12 25.2 30
2NH04501546 15 1 18 32.7 35
BHZ042
(3.5)
208/230-1-60 18.6 105 29 1.2 6.0
None - - - 30.5 40
2NP04501006 7.5/10 2 36.1/41.7 75.6/82.5 80/90
2NP04501506 11.3/15 2 54.2/62.5 98.2/108.6 100/110
2NE04501006 7.5 / 10 2 36.1 / 41.7 45.1 / 52.1 50 / 60
2NE04501506 11.3 / 15 2 54.2 / 62.5 67.7 / 78.1 70 / 80
208/230-3-60 13.4 88 21 1.2 6.0
None - - - 24 30
2NP04501025 7.5/10 1 20.8/24.1 50/54 60/60
2NP04501525 11.3/15 1 31.3/36.1 63/69.1 70/70
460-3-60 6.4 39 10 0.8 6.0
None - - - 11.8 15
2NP04501046 10 1 12 26.8 30
2NP04501546 15 1 18 34.3 35
BHZ048
(4.0)
208/230-1-60 21.8 117 34 1.2 6.0
None --- --- --- 34.5 45
2NP04501006 7.5 / 10 2 36.1 / 41.7 79.6 / 86.5 90 / 90
2NP04501506 11.3 / 15 2 54.2 / 62.5 102.2 / 112.6 110 / 125
2NP04502006 15 / 20 2 72.2 / 83.3 124.7 / 138.6 125 / 150
2NP04502506 18.8 / 25 2 90.3 / 104.2 147.3 / 164.7 150 / 175
2NE04501006 7.5 / 10 2 36.1 / 41.7 45.1 / 51.2 50 / 60
2NE04501506 11.3 / 15 2 54.2 / 62.5 67.7 / 78.1 70 / 80
2NE04502006 15 / 20 2 72.2 / 83.3 90.3 / 104.2 100 / 110
2NE04502506 18.8 / 25 2 90.3 / 104.2 112.8 / 130.2 125 / 150
208/230-3-60 13.7 83 21 1.2 6.0
None --- --- --- 24.3 30
2NP04501025 7.5 / 10 1 20.8 / 24.1 50.4 / 54.4 60 / 60
2NP04501525 11.3 / 15 1 31.3 / 36.1 63.4 / 69.4 70 / 70
2NP04502025 15 / 20 2 41.7 / 48.1 76.4 / 84.5 80 / 90
2NP04502525 18.8 / 25 2 52.1 / 60.1 89.5 / 99.5 90 / 100
460-3-60 6.2 41 10 0.8 6.0
None --- --- --- 11.5 15
2NP04501046 10 1 12 26.6 30
2NP04501546 15 1 18 34.1 35
2NH04502046 20 2 24.1 41.6 45
2NH04502546 25 2 30.1 49.1 50
