718419-YTG-D-0613
Johnson Controls Unitary Products 19
BHZ048 (4.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1200
77 59.8 3.1 28.6 23.7 18.9 - - - 56.5 3.5 27.6 22.7 17.7 - - -
72 56.3 3.0 36.6 31.8 26.9 22.1 - - 52.9 3.4 35.5 30.6 25.6 20.7 - -
67 52.7 2.9 44.6 39.8 34.9 30.1 25.3 - 49.3 3.3 43.4 38.5 33.5 28.6 23.6 -
62 47.9 2.9 47.9 46.9 41.3 36.5 31.6 26.8 45.4 3.3 45.4 44.9 39.9 35.0 30.0 25.0
57 50.4 2.9 50.4 47.8 43.0 38.1 33.3 28.4 46.1 3.3 46.1 44.3 39.3 34.4 29.4 24.5
1400
77 61.1 3.1 30.3 25.5 20.1 - - - 58.0 3.5 30.1 24.5 19.0 - - -
72 57.5 3.0 39.5 34.1 28.7 23.2 - - 54.3 3.4 38.5 33.0 27.4 21.9 - -
67 53.9 2.9 48.6 42.6 37.2 31.8 26.4 - 50.5 3.3 47.0 41.4 35.9 30.3 24.8 -
62 48.9 2.9 48.9 48.4 44.0 38.6 33.2 27.8 46.5 3.3 46.5 46.3 42.7 37.2 31.6 26.1
57 51.5 2.9 51.5 50.2 45.8 40.4 35.0 29.6 47.2 3.3 47.2 46.4 42.1 36.6 31.0 25.5
1600
77 62.5 3.1 32.0 27.3 21.3 - - - 59.4 3.5 32.5 26.4 20.2 - - -
72 58.8 3.0 42.3 36.4 30.4 24.4 - - 55.6 3.4 41.5 35.4 29.3 23.1 - -
67 55.1 3.0 52.6 45.4 39.5 33.5 27.5 - 51.8 3.4 50.6 44.4 38.3 32.1 26.0 -
62 50.0 2.9 50.0 50.0 46.6 40.7 34.7 28.7 47.7 3.3 47.7 47.7 45.6 39.4 33.3 27.1
57 52.6 3.0 52.6 52.6 48.6 42.6 36.6 30.7 48.4 3.4 48.4 48.4 44.9 38.8 32.6 26.5
1800
72 58.5 3.0 44.2 37.6 31.0 24.5 - - 55.7 3.4 43.5 36.7 29.9 23.1 - -
67 54.9 3.0 53.7 46.9 40.3 33.7 27.1 - 51.9 3.4 51.3 45.9 39.1 32.4 25.6 -
62 49.8 2.9 49.8 49.8 47.9 41.3 34.8 28.2 47.8 3.3 47.8 47.8 46.6 39.8 33.0 26.2
57 52.4 2.9 52.4 52.4 49.6 43.0 36.5 29.9 48.5 3.4 48.5 48.5 46.0 39.2 32.4 25.6
2000
72 58.3 3.0 46.1 38.9 31.7 24.5 - - 55.8 3.5 45.5 38.0 30.6 23.2 - -
67 54.7 2.9 54.7 48.3 41.2 34.0 26.8 - 52.0 3.4 52.0 47.5 40.0 32.6 25.2 -
62 49.6 2.9 49.6 49.6 49.2 42.0 34.8 27.6 47.8 3.3 47.8 47.8 47.7 40.2 32.8 25.4
57 52.2 2.9 52.2 52.2 50.7 43.5 36.3 29.1 48.6 3.4 48.6 48.6 47.0 39.5 32.1 24.7
95°F 105°F
1200
77 53.3 3.9 26.7 21.6 16.5 - - - 48.7 4.5 25.4 20.3 15.2 - - -
72 49.6 3.8 34.4 29.4 24.3 19.2 - - 45.6 4.4 33.0 27.9 22.8 17.7 - -
67 45.8 3.8 42.2 37.1 32.1 27.0 22.0 - 42.5 4.2 40.7 35.6 30.5 25.4 20.3 -
62 42.8 3.7 42.8 42.8 38.5 33.4 28.4 23.3 40.7 4.2 40.7 39.3 34.5 29.4 24.3 19.3
57 41.8 3.7 41.8 40.8 35.7 30.6 25.6 20.5 39.3 4.2 39.3 38.0 32.9 27.8 22.8 17.7
1400
77 54.9 3.9 29.8 23.5 17.8 - - - 49.8 4.5 30.0 22.2 16.4 - - -
72 51.0 3.9 37.6 31.9 26.2 20.5 - - 46.6 4.4 36.2 30.5 24.7 18.9 - -
67 47.2 3.8 45.3 40.3 34.6 28.9 23.2 - 43.4 4.3 42.5 38.7 33.0 27.2 21.4 -
62 44.1 3.7 44.1 44.1 41.5 35.8 30.1 24.4 41.6 4.2 41.6 40.9 37.4 31.6 25.8 20.0
57 43.0 3.7 43.0 42.5 38.5 32.8 27.1 21.4 40.2 4.2 40.2 39.5 35.6 29.9 24.1 18.3
1600
77 56.4 4.0 33.0 25.4 19.1 - - - 50.9 4.5 34.6 24.2 17.7 - - -
72 52.4 3.9 40.8 34.4 28.1 21.8 - - 47.6 4.4 39.5 33.0 26.6 20.1 - -
67 48.5 3.8 48.5 43.4 37.1 30.8 24.5 - 44.4 4.3 44.4 41.8 35.5 29.0 22.6 -
62 45.3 3.7 45.3 45.3 44.5 38.2 31.9 25.6 42.5 4.2 42.5 42.5 40.2 33.7 27.3 20.8
57 44.2 3.7 44.2 44.2 41.3 35.0 28.6 22.3 41.0 4.2 41.0 41.0 38.3 31.9 25.4 19.0
1800
72 52.9 3.9 42.8 35.8 28.8 21.8 - - 48.0 4.4 41.7 34.5 27.3 20.2 - -
67 48.9 3.8 48.9 45.0 38.0 31.0 24.0 - 44.7 4.3 44.7 42.8 36.5 29.3 22.2 -
62 45.7 3.7 45.7 45.7 45.3 38.3 31.3 24.3 42.9 4.2 42.9 42.9 41.2 34.0 26.8 19.7
57 44.6 3.8 44.6 44.6 42.3 35.3 28.3 21.3 41.4 4.3 41.4 41.4 39.4 32.3 25.1 17.9
2000
72 53.3 3.9 44.8 37.1 29.5 21.8 - - 48.4 4.4 43.8 36.0 28.1 20.2 - -
67 49.3 3.8 49.3 46.6 38.9 31.2 23.5 - 45.1 4.3 45.1 43.7 37.5 29.6 21.8 -
62 46.1 3.7 46.1 46.1 46.1 38.4 30.7 23.1 43.2 4.3 43.2 43.2 42.1 34.3 26.4 18.5
57 44.9 3.8 44.9 44.9 43.3 35.6 27.9 20.3 41.7 4.3 41.7 41.7 40.5 32.6 24.8 16.9
To Next Page
