718419-YTG-D-0613
Johnson Controls Unitary Products 29
BHQ042 (3.5 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1300
77 59.3 2.4 31.0 25.8 19.7 - - - 54.6 2.8 29.6 23.9 18.0 - - -
72 54.7 2.4 40.1 34.0 27.9 21.7 - - 50.3 2.8 37.6 31.7 25.8 19.9 - -
67 50.0 2.4 49.3 42.2 36.0 29.9 23.8 - 46.0 2.8 45.6 39.5 33.6 27.7 21.7 -
62 45.6 2.4 45.6 45.6 43.8 37.6 31.5 25.3 42.0 2.8 42.0 42.0 40.6 34.7 28.8 22.9
1400
77 58.4 2.4 30.6 25.5 19.4 - - - 54.4 2.9 30.0 24.0 18.0 - - -
72 53.9 2.4 39.7 33.6 27.5 21.4 - - 50.1 2.8 37.8 31.8 25.8 19.8 - -
67 49.3 2.4 48.8 41.7 35.6 29.4 23.3 - 45.8 2.8 45.6 39.6 33.6 27.6 21.6 -
62 45.0 2.4 45.0 45.0 43.2 37.1 30.9 24.8 41.9 2.8 41.9 41.9 40.6 34.7 28.7 22.7
57 44.9 2.4 44.9 44.9 44.7 38.6 32.5 26.4 42.1 2.8 42.1 42.1 41.7 35.7 29.7 23.7
1500
77 57.6 2.5 30.2 25.2 19.1 - - - 54.2 2.9 30.4 24.1 18.1 - - -
72 53.1 2.5 39.3 33.2 27.1 21.0 - - 49.9 2.9 38.0 31.9 25.8 19.8 - -
67 48.6 2.5 48.3 41.1 35.1 29.0 22.9 - 45.7 2.9 45.5 39.7 33.6 27.6 21.5 -
62 44.3 2.5 44.3 44.3 42.6 36.5 30.4 24.3 41.7 2.8 41.7 41.7 40.7 34.6 28.5 22.5
57 44.2 2.5 44.2 44.2 44.1 38.0 32.0 25.9 41.9 2.8 41.9 41.9 41.7 35.6 29.6 23.5
1600
77 56.7 2.5 29.8 24.9 18.9 - - - 54.0 2.9 30.9 24.2 18.1 - - -
72 52.3 2.5 38.8 32.8 26.7 20.7 - - 49.7 2.9 38.2 32.0 25.9 19.7 - -
67 47.9 2.5 47.9 40.6 34.6 28.5 22.5 - 45.5 2.9 45.5 39.8 33.7 27.5 21.3 -
62 43.6 2.5 43.6 43.6 42.0 35.9 29.9 23.8 41.5 2.9 41.5 41.5 40.7 34.6 28.4 22.3
57 43.5 2.5 43.5 43.5 43.5 37.5 31.4 25.4 41.7 2.9 41.7 41.7 41.7 35.6 29.4 23.3
1650
72 53.1 2.5 40.6 34.3 28.0 21.7 - - 49.9 2.9 40.0 33.5 27.0 20.5 - -
67 48.6 2.5 48.6 42.5 36.2 29.9 23.6 - 45.6 2.9 45.6 41.6 35.1 28.6 22.1 -
62 44.3 2.5 44.3 44.3 43.4 37.1 30.8 24.5 41.7 2.9 41.7 41.7 41.3 34.8 28.3 21.8
57 44.2 2.5 44.2 44.2 44.2 37.9 31.6 25.3 41.9 2.9 41.9 41.9 41.9 35.4 28.9 22.4
1700
72 53.8 2.5 42.3 35.8 29.2 22.6 - - 50.1 2.9 41.8 34.9 28.1 21.2 - -
67 49.3 2.5 49.3 44.5 37.8 31.2 24.6 - 45.8 2.9 45.8 43.4 36.5 29.7 22.8 -
62 44.9 2.5 44.9 44.9 44.9 38.4 31.8 25.2 41.8 2.9 41.8 41.8 41.8 35.0 28.1 21.3
57 44.8 2.5 44.8 44.8 44.8 38.3 31.7 25.1 42.0 2.9 42.0 42.0 42.0 35.2 28.3 21.5
95°F 105°F
1300
77 50.0 3.3 28.2 22.1 16.4 - - - 45.6 3.7 30.0 21.0 15.1 - - -
72 46.0 3.3 35.1 29.4 23.7 18.1 - - 41.9 3.7 34.1 28.3 22.5 16.7 - -
67 42.0 3.2 42.0 36.8 31.1 25.4 19.7 - 38.2 3.7 38.2 35.6 29.9 24.1 18.3 -
62 38.5 3.2 38.5 38.5 37.5 31.8 26.1 20.4 35.7 3.7 35.7 35.7 35.0 29.2 23.4 17.6
1400
77 50.4 3.3 29.5 22.6 16.7 - - - 46.4 3.7 31.0 21.5 15.5 - - -
72 46.4 3.3 35.9 30.0 24.2 18.3 - - 42.6 3.7 34.9 29.0 23.0 17.0 - -
67 42.4 3.2 42.4 37.5 31.6 25.8 19.9 - 38.8 3.7 38.8 36.4 30.5 24.6 18.6 -
62 38.8 3.2 38.8 38.8 38.1 32.2 26.4 20.5 36.3 3.6 36.3 36.3 35.7 29.7 23.8 17.8
57 39.3 3.2 39.3 39.3 38.6 32.7 26.9 21.0 36.4 3.6 36.4 36.4 36.1 30.1 24.1 18.2
1500
77 50.8 3.3 30.7 23.0 17.0 - - - 47.1 3.7 32.1 22.0 15.8 - - -
72 46.8 3.2 36.7 30.6 24.6 18.5 - - 43.3 3.6 35.8 29.6 23.5 17.3 - -
67 42.7 3.2 42.7 38.3 32.2 26.1 20.1 - 39.5 3.6 39.5 37.3 31.2 25.0 18.9 -
62 39.1 3.2 39.1 39.1 38.8 32.7 26.7 20.6 36.9 3.6 36.9 36.9 36.4 30.3 24.1 18.0
57 39.6 3.2 39.6 39.6 39.3 33.2 27.1 21.1 37.0 3.6 37.0 37.0 36.9 30.7 24.6 18.4
1600
77 51.2 3.3 31.9 23.5 17.3 - - - 47.9 3.6 33.1 22.5 16.1 - - -
72 47.2 3.2 37.5 31.2 25.0 18.7 - - 44.0 3.6 36.6 30.3 24.0 17.6 - -
67 43.1 3.2 43.1 39.0 32.7 26.5 20.2 - 40.1 3.6 40.1 38.1 31.8 25.5 19.1 -
62 39.4 3.2 39.4 39.4 39.4 33.2 26.9 20.7 37.5 3.6 37.5 37.5 37.2 30.8 24.5 18.2
57 39.9 3.2 39.9 39.9 39.9 33.7 27.4 21.2 37.7 3.6 37.7 37.7 37.7 31.3 25.0 18.7
1650
72 46.7 3.3 39.4 32.7 26.0 19.3 - - 43.1 3.7 38.1 31.4 24.7 17.9 - -
67 42.7 3.2 42.7 40.6 34.0 27.3 20.6 - 39.3 3.7 39.3 38.3 32.8 26.0 19.3 -
62 39.1 3.2 39.1 39.1 39.1 32.4 25.7 19.0 36.8 3.6 36.8 36.8 36.6 29.8 23.1 16.4
57 39.6 3.2 39.6 39.6 39.6 32.9 26.2 19.5 36.9 3.6 36.9 36.9 36.9 30.1 23.4 16.7
1700
72 46.3 3.3 41.2 34.1 27.0 19.8 - - 42.2 3.7 39.7 32.5 25.4 18.3 - -
67 42.3 3.3 42.3 42.3 35.3 28.2 21.1 - 38.5 3.7 38.5 38.5 33.7 26.6 19.5 -
62 38.7 3.2 38.7 38.7 38.7 31.6 24.5 17.3 36.0 3.7 36.0 36.0 36.0 28.8 21.7 14.6
57 39.2 3.2 39.2 39.2 39.2 32.1 25.0 17.8 36.1 3.7 36.1 36.1 36.1 29.0 21.8 14.7
