718419-YTG-D-0613
Johnson Controls Unitary Products 31
BHQ048 (4.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1300
77 63.0 2.8 29.9 24.4 19.2 - - - 59.5 3.2 29.1 23.7 18.3 - - -
72 57.9 2.7 37.3 32.2 27.1 21.9 - - 54.6 3.2 36.8 31.4 26.0 20.6 - -
67 52.9 2.7 44.7 40.0 34.9 29.7 24.6 - 49.8 3.1 44.5 39.1 33.7 28.3 22.9 -
62 48.3 2.7 48.3 48.3 42.0 36.9 31.8 26.6 45.6 3.1 45.6 45.6 41.2 35.8 30.4 25.0
1400
77 63.7 2.8 31.2 25.6 19.9 - - - 60.1 3.2 30.5 24.7 18.9 - - -
72 58.6 2.8 39.3 33.7 28.0 22.4 - - 55.2 3.2 38.5 32.7 26.9 21.0 - -
67 53.5 2.7 47.4 41.7 36.1 30.5 24.8 - 50.3 3.2 46.5 40.6 34.8 29.0 23.2 -
62 48.8 2.7 48.8 48.8 43.5 37.9 32.2 26.6 46.0 3.1 46.0 46.0 42.5 36.7 30.9 25.1
57 48.5 2.7 48.5 48.5 46.4 40.8 35.1 29.5 46.0 3.1 46.0 46.0 44.1 38.3 32.5 26.7
1500
77 64.4 2.9 32.5 26.8 20.6 - - - 60.7 3.3 32.0 25.7 19.5 - - -
72 59.3 2.8 41.3 35.1 29.0 22.8 - - 55.7 3.2 40.2 33.9 27.7 21.5 - -
67 54.1 2.8 50.0 43.5 37.4 31.2 25.1 - 50.8 3.2 48.4 42.2 35.9 29.7 23.4 -
62 49.4 2.7 49.4 49.4 45.0 38.9 32.7 26.6 46.5 3.1 46.5 46.5 43.9 37.6 31.4 25.1
57 49.0 2.7 49.0 49.0 48.0 41.8 35.7 29.6 46.4 3.1 46.4 46.4 45.5 39.3 33.0 26.8
1600
77 65.2 2.9 33.8 28.0 21.3 - - - 61.3 3.3 33.4 26.7 20.1 - - -
72 59.9 2.8 43.3 36.6 30.0 23.3 - - 56.3 3.2 41.9 35.2 28.5 21.9 - -
67 54.7 2.8 52.7 45.3 38.6 32.0 25.3 - 51.3 3.2 50.3 43.7 37.0 30.3 23.7 -
62 49.9 2.8 49.9 49.9 46.5 39.9 33.2 26.6 46.9 3.2 46.9 46.9 45.2 38.5 31.9 25.2
57 49.6 2.8 49.6 49.6 49.6 42.9 36.3 29.6 46.9 3.2 46.9 46.9 46.9 40.2 33.6 26.9
1800
72 61.1 2.9 48.1 40.4 32.8 25.2 - - 56.7 3.2 45.2 37.8 30.5 23.1 - -
67 55.7 2.8 54.7 49.9 42.3 34.6 27.0 - 51.7 3.2 51.2 46.9 39.5 32.1 24.8 -
62 50.9 2.8 50.9 50.9 49.2 41.5 33.9 26.3 47.3 3.2 47.3 47.3 46.4 39.1 31.7 24.4
57 50.5 2.8 50.5 50.5 50.5 42.9 35.3 27.6 47.3 3.2 47.3 47.3 47.3 39.9 32.6 25.2
2000
72 62.2 2.9 52.8 44.2 35.6 27.0 - - 57.2 3.2 48.5 40.4 32.4 24.3 - -
67 56.8 2.8 56.8 54.6 45.9 37.3 28.7 - 52.2 3.2 52.2 50.0 42.0 33.9 25.9 -
62 51.8 2.8 51.8 51.8 51.8 43.2 34.6 26.0 47.7 3.2 47.7 47.7 47.7 39.6 31.6 23.5
57 51.5 2.8 51.5 51.5 51.5 42.9 34.3 25.7 47.7 3.2 47.7 47.7 47.7 39.6 31.6 23.5
95°F 105°F
1300
77 55.9 3.7 28.3 23.0 17.4 - - - 51.0 4.2 26.9 21.4 15.8 - - -
72 51.3 3.6 36.3 30.6 25.0 19.3 - - 46.8 4.2 34.2 28.7 23.1 17.6 - -
67 46.8 3.6 44.3 38.3 32.6 26.9 21.3 - 42.7 4.1 41.5 35.9 30.4 24.8 19.3 -
62 42.8 3.6 42.8 42.8 40.4 34.7 29.0 23.4 39.0 4.1 39.0 39.0 35.9 30.4 24.8 19.3
1400
77 56.4 3.7 29.9 23.9 17.9 - - - 51.7 4.2 29.3 22.4 16.5 - - -
72 51.8 3.6 37.7 31.7 25.7 19.7 - - 47.5 4.1 35.9 30.0 24.1 18.1 - -
67 47.2 3.6 45.5 39.5 33.5 27.5 21.5 - 43.3 4.1 42.5 37.5 31.6 25.7 19.8 -
62 43.2 3.6 43.2 43.2 41.5 35.5 29.5 23.5 39.5 4.1 39.5 39.5 37.3 31.4 25.5 19.6
57 43.5 3.6 43.5 43.5 41.9 35.9 29.9 23.9 40.3 4.1 40.3 40.3 38.5 32.6 26.6 20.7
1500
77 56.9 3.7 31.4 24.7 18.3 - - - 52.5 4.2 31.6 23.4 17.1 - - -
72 52.2 3.6 39.1 32.7 26.4 20.1 - - 48.2 4.1 37.6 31.3 25.0 18.7 - -
67 47.6 3.6 46.7 40.8 34.5 28.1 21.8 - 43.9 4.1 43.5 39.1 32.9 26.6 20.3 -
62 43.6 3.6 43.6 43.6 42.7 36.4 30.0 23.7 40.1 4.0 40.1 40.1 38.8 32.5 26.2 19.9
57 43.8 3.6 43.8 43.8 43.1 36.7 30.4 24.0 40.9 4.0 40.9 40.9 40.0 33.7 27.4 21.1
1600
77 57.4 3.7 33.0 25.5 18.8 - - - 53.2 4.1 34.0 24.4 17.8 - - -
72 52.7 3.6 40.5 33.8 27.1 20.4 - - 48.8 4.1 39.2 32.6 25.9 19.3 - -
67 48.0 3.6 48.0 42.1 35.4 28.7 22.0 - 44.5 4.0 44.5 40.8 34.1 27.5 20.8 -
62 44.0 3.6 44.0 44.0 43.9 37.2 30.5 23.8 40.6 4.0 40.6 40.6 40.2 33.6 26.9 20.3
57 44.2 3.6 44.2 44.2 44.2 37.5 30.9 24.2 41.5 4.0 41.5 41.5 41.5 34.8 28.2 21.5
1800
72 52.4 3.6 42.3 35.2 28.1 21.0 - - 48.7 4.1 41.3 34.2 27.0 19.9 - -
67 47.8 3.6 47.8 43.8 36.7 29.6 22.5 - 44.3 4.0 44.3 42.0 35.6 28.4 21.3 -
62 43.8 3.6 43.8 43.8 43.7 36.6 29.6 22.5 40.5 4.0 40.5 40.5 40.3 33.2 26.0 18.9
57 44.0 3.6 44.0 44.0 44.0 36.9 29.9 22.8 41.3 4.0 41.3 41.3 41.3 34.2 27.1 19.9
2000
72 52.2 3.6 44.1 36.6 29.1 21.7 - - 48.5 4.1 43.4 35.7 28.1 20.5 - -
67 47.6 3.6 47.6 45.5 38.0 30.5 23.0 - 44.2 4.0 44.2 43.2 37.0 29.4 21.8 -
62 43.6 3.6 43.6 43.6 43.6 36.1 28.6 21.1 40.4 4.0 40.4 40.4 40.4 32.8 25.2 17.6
57 43.8 3.6 43.8 43.8 43.8 36.3 28.9 21.4 41.2 4.0 41.2 41.2 41.2 33.6 26.0 18.4
