York AFFINITY BHZ - Page 41

718419-YTG-D-0613
Johnson Controls Unitary Products 41
BHZ048
(4.0)
1200
55
MBH 13.6 18.6 23.6 28.6 33.6 38.6 43.6 48.6
KW 2.28 2.45 2.63 2.81 2.99 3.16 3.34 3.52
70
MBH 12.0 17.0 22.0 27.0 32.0 37.0 42.0 47.0
KW 2.81 2.99 3.16 3.34 3.52 3.70 3.87 4.05
80
MBH 9.4 14.4 19.4 24.4 29.4 34.4 39.4 44.4
KW 3.19 3.37 3.55 3.72 3.90 4.08 4.26 4.44
1400
55
MBH 15.40 20.40 25.40 30.40 35.40 40.40 45.40 50.40
KW 2.16 2.34 2.52 2.70 2.87 3.05 3.23 3.41
70
MBH 13.85 18.85 23.85 28.85 33.85 38.86 43.86 48.86
KW 2.70 2.87 3.05 3.23 3.41 3.58 3.76 3.94
80
MBH 11.18 16.19 21.19 26.19 31.19 36.19 41.19 46.19
KW 3.08 3.26 3.44 3.61 3.79 3.97 4.15 4.32
1600
55
MBH 17.21 22.2 27.2 32.2 37.2 42.2 47.2 52.2
KW 2.05 2.23 2.40 2.58 2.76 2.94 3.11 3.29
70
MBH 15.7 20.7 25.7 30.7 35.7 40.7 45.7 50.7
KW 2.58 2.76 2.94 3.12 3.29 3.47 3.65 3.83
80
MBH 13.0 18.0 23.0 28.0 33.0 38.0 43.0 48.0
KW 2.97 3.15 3.33 3.50 3.68 3.86 4.04 4.21
1800
55
MBH 19.04 24.04 29.04 34.04 39.04 44.04 49.04 54.05
KW 1.94 2.11 2.29 2.47 2.65 2.82 3.00 3.18
70
MBH 17.49 22.49 27.49 32.49 37.50 42.50 47.50 52.50
KW 2.47 2.65 2.82 3.00 3.18 3.36 3.54 3.71
80
MBH 14.83 19.83 24.83 29.83 34.83 39.83 44.83 49.83
KW 2.85 3.03 3.21 3.39 3.57 3.74 3.92 4.10
2000
55
MBH 20.9 25.9 30.9 35.9 40.9 45.9 50.9 55.9
KW 1.82 2.00 2.18 2.36 2.53 2.71 2.89 3.07
70
MBH 19.3 24.3 29.3 34.3 39.3 44.3 49.3 54.3
KW 2.36 2.53 2.71 2.89 3.07 3.24 3.42 3.60
80
MBH 16.6 21.6 26.6 31.6 36.6 41.6 46.6 51.6
KW 2.74 2.92 3.09 3.27 3.45 3.63 3.81 3.98
BHZ060
(5.0)
1500
55
MBH 24.54 28.20 32.46 37.44 43.23 49.98 57.85 67.02
KW 3.12 3.34 3.56 3.79 4.01 4.23 4.45 4.67
70
MBH 22.90 26.57 30.83 35.80 41.60 48.35 56.21 65.38
KW 3.56 3.78 4.00 4.22 4.44 4.66 4.89 5.11
80
MBH 21.74 25.40 29.67 34.64 40.43 47.18 55.05 64.22
KW 4.07 4.30 4.52 4.74 4.96 5.18 5.40 5.62
1750
55
MBH 24.18 27.84 32.11 37.08 42.87 49.62 57.49 66.66
KW 3.20 3.42 3.64 3.86 4.08 4.31 4.53 4.75
70
MBH 22.55 26.21 30.47 35.45 41.24 47.99 55.86 65.02
KW 3.63 3.85 4.08 4.30 4.52 4.74 4.96 5.18
80
MBH 21.38 25.04 29.31 34.28 40.08 46.83 54.69 63.86
KW 4.15 4.37 4.59 4.82 5.04 5.26 5.48 5.70
2000
55
MBH 23.78 27.44 31.71 36.68 42.47 49.23 57.09 66.26
KW 3.28 3.50 3.73 3.95 4.17 4.39 4.61 4.83
70
MBH 22.15 25.81 30.08 35.05 40.84 47.59 55.46 64.63
KW 3.72 3.94 4.16 4.38 4.60 4.83 5.05 5.27
80
MBH 20.99 24.65 28.91 33.89 39.68 46.43 54.30 63.46
KW 4.24 4.46 4.68 4.90 5.12 5.34 5.56 5.79
2250
55
MBH 23.38 27.05 31.31 36.28 42.08 48.83 56.70 65.86
KW 3.37 3.59 3.81 4.03 4.25 4.48 4.70 4.92
70
MBH 21.75 25.41 29.68 34.65 40.44 47.20 55.06 64.23
KW 3.80 4.02 4.25 4.47 4.69 4.91 5.13 5.35
80
MBH 20.59 24.25 28.52 33.49 39.28 46.03 53.90 63.07
KW 4.32 4.54 4.76 4.99 5.21 5.43 5.65 5.87
2500
55
MBH 22.39 26.05 30.32 35.29 41.08 47.83 55.70 64.87
KW 3.58 3.80 4.02 4.24 4.47 4.69 4.91 5.13
70
MBH 20.76 24.42 28.69 33.66 39.45 46.20 54.07 63.24
KW 4.02 4.24 4.46 4.68 4.90 5.12 5.34 5.57
80
MBH 19.59 23.26 27.52 32.49 38.29 45.04 52.91 62.07
KW 4.53 4.76 4.98 5.20 5.42 5.64 5.86 6.08
1. These Capacities are net capacities - the indoor motor heat has been added.
2. These power inputs are total power inputs - the indoor motor watts have been added.
BHZ024-060 (Continued)
Model
(Tons)
Air Over Evaporator
Coil
Capacity
1
& kW
2
Outdoor Temperature (°F @ 72% RH)
CFM DB (°F
) -10 0 10 20 30 40 50 60
